Model: EAP620 HD NEW
EAN: 4897098680315

TP-Link AX1800 Ceiling Mount WiFi 6 Access Point

Manufacturer:
TP-LINK
TP-Link AX1800 Ceiling Mount WiFi 6 Access Point, 2.4 GHz, 5 GHz, 1800 Mbit/s, SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK, 10,100,1000 Mbit/s
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link AX1800 Ceiling Mount WiFi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
  • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds
  • High-Density Connectivity: 4× increased capacity to connect more devices simultaneously
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralized Cloud Management, and Intelligent Monitoring
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management
  • Ultra-Slim Design: Φ160 mm × 33.6 mm elegant design brings more agility
  • Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations
  • Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment
  • PoE+ Powered: Supports DC (adapter included), 802.3at PoE+, and Passive PoE for flexible installations
  • Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies

Product Properties

  • Model
  • EAP620 HD NEW
  • EAN
  • 4897098680315
  • Antenna
  • Antenna direction type
  • Omni-directional
  • Antenna gain level (max)
  • 6 dBi
  • Antenna type
  • Internal
  • Bullet points
  • Point
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management
    High-Density Connectivity: 4× increased capacity to connect more devices simultaneously
    Integrated into Omada SDN
    Omada Mesh
    PoE+ Powered
    Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations
    Secure Guest Network
    Ultra-Fast WiFi 6 Speeds
    Ultra-Slim Design: Φ160 mm × 33.6 mm elegant design brings more agility
  • Certificates
  • Certification
  • CE, FCC, RoHS
  • Design
  • Placement
  • Ceiling, Wall
  • Product colour
  • White
  • Reset button
  • Yes
  • Features
  • 2.4 GHz
  • Yes
  • 5 GHz
  • Yes
  • Band steering
  • Yes
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • Frequency band
  • 2.4 - 5 GHz
  • Maximum data transfer rate
  • 1800 Mbit/s
  • Maximum data transfer rate (2.4 GHz)
  • 574 Mbit/s
  • Maximum data transfer rate (5 GHz)
  • 1201 Mbit/s
  • MIMO
  • Yes
  • MIMO type
  • Multi User MIMO
  • Modulation
  • 1024-QAM, OFDM
  • Networking standards
  • IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
  • Quality of Service (QoS) support
  • Yes
  • Rate limiting
  • Yes
  • Transmitting power (CE)
  • 20/23 dBm
  • Transmitting power (FCC)
  • 23 dBm
  • Virtual LAN features
  • VLAN mapping
  • VLAN support
  • Yes
  • Wi-Fi Multimedia (WMM)/(WME)
  • Yes
  • Management features
  • Firmware upgradeable
  • Yes
  • Syslog
  • Yes
  • Web-based management
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • AC adapter included
  • Yes
  • Quantity per pack
  • 1 pc(s)
  • Quick start guide
  • Yes
  • Packaging data
  • Package type
  • Box
  • Performance
  • Compatible operating systems
  • Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
  • Ports & interfaces
  • DC-in jack
  • Yes
  • Ethernet LAN (RJ-45) ports
  • 1
  • Power
  • Output voltage
  • 12 V
  • Power over Ethernet (PoE)
  • Yes
  • Security
  • Number of SSID supported
  • 16
  • Security algorithms
  • SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK
  • Service Set Identifier (SSID) features
  • Multiple SSIDs
  • Weight & dimensions
  • Depth
  • 160 mm
  • Height
  • 33.6 mm
  • Width
  • 160 mm
