Description

APC Smart-UPS SMT1500RMI2UC - 4x C13, USB, Rackmount 2U, SmartConnect, 1500VA. UPS topology: Line-Interactive, Output power capacity: 1.5 kVA, Output power: 1000 W. AC outlet types: C13 coupler, IEC Jumpers, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 6 year(s), Battery recharge time: 3 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Certification: CE, EAC, EN / IEC 62040-1, EN / IEC 62040-2, Energy Star 1.0 (EU), RCM, TÜV, VDE

Product Properties

Manufacturer
APC

Model
SMT1500RMI2UC

EAN
731304333005

Battery

Automatic battery test
Yes

Battery life (max)
6 year(s)

Battery recharge time
3 h

Battery technology
Sealed Lead Acid (VRLA)

Cold start
Yes

Hot-swap battery
Yes

Number of batteries supported
1

Certificates

Certification
CE, EAC, EN / IEC 62040-1, EN / IEC 62040-2, Energy Star 1.0 (EU), RCM, TÜV, VDE

Design

Display type
LCD

Form factor
Rackmount

LED indicators
Yes

Product colour
Black

Rack capacity
2U

Features

Audible alarm modes
Alarm when on battery, Low battery alarm

Audible alarm(s)
Yes

Auto-restart
Yes

Input frequency
50/60 Hz

Input operation voltage (max)
302 V

Input operation voltage (min)
151 V

Noise level
46 dB

Output frequency
50/60 Hz

Output operation voltage (max)
240 V

Output operation voltage (min)
220 V

Output power
1000 W

Output power capacity
1.5 kVA

Response time
10 ms

Surge energy rating
459 J

UPS topology
Line-Interactive

Waveform
Sine

Logistics data

Harmonized System (HS) code
85078000

Products per pallet
8 pc(s)

Total carbon footprint (kg of CO2e)
1416.6

Operational conditions

Non-operating altitude
0 - 15000 m

Operating altitude
0 - 3000 m

Operating relative humidity (H-H)
0 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
0 - 95%

Storage temperature (T-T)
-15 - 45 °C

Other features

Output voltage
230 V

Packaging content

Cables included
RS-232, USB cable

Manual
Yes

Rack mount kit
Yes

Packaging data

Package depth
603 mm

Package height
251 mm

Package weight
31.9 kg

Package width
594 mm

Resource CD
Yes

Ports & interfaces

AC outlet types
C13 coupler, IEC Jumpers

AC outlets quantity
4 AC outlet(s)

Power plug
C14 coupler

Serial interface
Yes

Serial interface type
RJ-45

SmartSlot
Yes

USB port
Yes

Sustainability

Sustainability certificates
ENERGY STAR, Green Premium

Weight & dimensions

Depth
477 mm

Height
86 mm

Weight
26.1 kg

Width
432 mm
