D-Link DSS-200G-10MPP/B network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
Roll over image to zoom inClick to Open expanded view
D-Link DSS-200G-10MPP/B network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
D-Link DSS-200G-10MPP/B network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
D-Link DSS-200G-10MPP/B network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
D-Link DSS-200G-10MPP/B network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
Print
Model: DSS-200G-10MPP/B
EAN: 790069470653

D-Link DSS-200G-10MPP/B network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey

Manufacturer:
D-Link
D-Link DSS-200G-10MPP/B, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), 1U
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

D-Link DSS-200G-10MPP/B. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Installed SFP modules quantity: 2. Full duplex. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt,.... Power over Ethernet (PoE). Form factor: 1U
  • High PoE budgets and support for IEEE 802.3bt 90 W PoE
  • 6 kV surge protection on all PoE ports
  • Alarm Port and four-stage PoE usage indicator light
  • Smart Fan design
  • Surveillance traffic optimization
  • Auto-detect ONVIF devices
  • Built-in SNMP MIB
  • Surveillance VLAN
  • Easy deployment with automatic configuration
  • NDAA Compliant
  • D-Link Lifetime Warranty after Registration

Product Properties

  • Model
  • DSS-200G-10MPP/B
  • EAN
  • 790069470653
  • Bullet points
  • Point
  • 6 kV surge protection on all PoE ports
    Alarm Port and four-stage PoE usage indicator light
    Auto-detect ONVIF devices
    Built-in SNMP MIB
    D-Link Lifetime Warranty after Registration
    Easy deployment with automatic configuration
    High PoE budgets and support for IEEE 802.3bt 90 W PoE
    NDAA Compliant
    Smart Fan design
    Surveillance traffic optimization
    Surveillance VLAN
  • Certificates
  • Compliance certificates
  • BSMI, CB, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), cUL
  • Data transmission
  • Forwarding rate
  • 14.88 Mpps
  • Jumbo frames
  • 10240
  • Jumbo frames support
  • Yes
  • MAC address table
  • 8000 entries
  • Number of queues
  • 4
  • Packet buffer memory
  • 4.1 MB
  • Switching capacity
  • 20 Gbit/s
  • Design
  • Form factor
  • 1U
  • LED indicators
  • Activity, Alarm, Link, Power, Speed
  • Number of fans
  • 1 fan(s)
  • Product colour
  • Grey
  • Reset button
  • Yes
  • Management features
  • MIB support
  • • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention • RFC2233 Interface Group MIB • RFC2665 Ether-like MIB • RFC4363 IEEE 802.1p MIB • ZoneDefense MIB • Private MIB • RFC951 BootP client • RFC1542 BootP/DHCP client • RFC2236 IGMP Snooping
  • Quality of Service (QoS) support
  • Yes
  • Switch layer
  • L2
  • Switch type
  • Managed
  • Traffic classification
  • Yes
  • Web-based management
  • Yes
  • Multicast features
  • Multicast features
  • Controllable multicast
  • Multicast support
  • Yes
  • Network
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Broadcast storm control
  • Yes
  • Ethernet LAN data rates
  • 1000 Mbit/s
  • Flow control support
  • Yes
  • Full duplex
  • Yes
  • Half duplex
  • Yes
  • Head-of-line (HOL) blocking
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
  • Number of VLANs
  • 4094
  • Port mirroring
  • Yes
  • Rate limiting
  • Yes
  • Spanning tree protocol
  • Yes
  • Virtual LAN features
  • Voice VLAN
  • VLAN support
  • Yes
  • Operational conditions
  • Heat dissipation
  • 87 BTU/h
  • Operating relative humidity (H-H)
  • 0 - 95%
  • Operating temperature (T-T)
  • -5 - 50 °C
  • Storage relative humidity (H-H)
  • 0 - 95%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Performance
  • Fanless
  • No
  • Flash memory
  • 32 MB
  • Internal memory
  • 128 MB
  • Mean time between failures (MTBF)
  • 508112 h
  • Memory type
  • DDR3-SDRAM
  • Noise level
  • 50.6 dB
  • Ports & interfaces
  • Installed SFP modules quantity
  • 2
  • Switch Number of Ports
  • 8
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • AC input frequency
  • 50/60 Hz
  • AC input voltage
  • 100 - 240 V
  • Input current
  • 3 A
  • Input voltage
  • 100 - 240 V
  • Power consumption (max)
  • 267.5 W
  • Power source
  • AC
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet (PoE) ports quantity
  • 8
  • Power over Ethernet (PoE) power per port
  • 90 W
  • Total Power over Ethernet (PoE) budget
  • 242 W
  • Security
  • IGMP snooping
  • Yes
  • Password protection
  • Yes
  • Queue scheduling algorithms
  • Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
  • SSH/SSL support
  • Yes
  • Sustainability
  • Sustainability certificates
  • UL ECOLOGO
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Depth
  • 230 mm
  • Height
  • 44 mm
  • Weight
  • 2.05 kg
  • Width
  • 280 mm
