Description

NEC NP-P554U. Projector brightness: 5300 ANSI lumens, Projection technology: LCD, Projector native resolution: WUXGA (1920x1200). Light source type: Lamp, Service life of light source: 4000 h, Service life of light source (economic mode): 8000 h. Focus: Manual, Focal length range: 17.2 - 27.7 mm, Aperture range (F-F): 1.5 - 2.08. Analog signal format system: NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM, Supported graphics resolutions: 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600..., Supported video modes: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p. Serial interface type: RS-232, HDMI connector type: Full-size

Product Properties

Manufacturer
NEC

Model
60004329

EAN
5028695613157

Design

Placement
Desktop, Ceiling

Product colour
White

Product type
Standard throw projector

Display

Built-in display
No

Features

Certification
UL(UL60950-1, FCC 15 B, CUL(UL60950-1, CES-003 B)

HDCP
Yes

Noise level
37 dB

Noise level (economic mode)
34 dB

Lens system

Aperture range (F-F)
1.5 - 2.08

Focal length range
17.2 - 27.7 mm

Focus
Manual

Horizontal lens shift range
-15 - 15%

Throw ratio
1.2 - 2.0:1

Vertical lens shift range
0 - 55%

Zoom capability
Yes

Zoom ratio
1.6:1

Zoom type
Manual

Light source

Lamp power
330 W

Lamps quantity
1 lamp(s)

Light source type
Lamp

Service life of light source
4000 h

Service life of light source (economic mode)
8000 h

Logistics data

Harmonized System (HS) code
85286200

Multimedia

Built-in speaker(s)
Yes

RMS rated power
20 W

Network

Ethernet LAN
Yes

Ethernet LAN (RJ-45) ports
1

Ethernet LAN data rates
10,100 Mbit/s

Wi-Fi
No

Operational conditions

Operating relative humidity (H-H)
20 - 80%

Operating temperature (T-T)
5 - 40 °C

Storage temperature (T-T)
-10 - 50 °C

Other features

RS-232 ports
1

Packaging content

Batteries included
Yes

Cables included
AC, VGA

Manual
Yes

Remote control included
Yes

Ports & interfaces

AC (power) in
Yes

Audio (L/R) in
1

Component video (YPbPr/YCbCr) in
0

Composite video in
1

DVI port
No

HDBaseT port
Yes

HDMI connector type
Full-size

HDMI ports
2

PC Audio in
Yes

PC Audio out
Yes

S-Video inputs quantity
0

Serial interface type
RS-232

USB 2.0 ports quantity
1

VGA (D-Sub) ports quantity
2

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Auto power off
Yes

Power consumption (economy mode)
286 W

Power consumption (standby)
2 W

Power consumption (typical)
457 W

Power source
AC

Projector

Contrast ratio (typical)
20000:1

Horizontal synchronization (max)
100 kHz

Horizontal synchronization (min)
15 kHz

Keystone correction, horizontal
-20 - 20°

Keystone correction, vertical
-30 - 30°

Matrix size
1.63 cm (0.64")

Projection distance
0.8 - 14.5 m

Projection technology
LCD

Projector brightness
5300 ANSI lumens

Projector native resolution
WUXGA (1920x1200)

Screen size compatibility
762 - 7620 mm (30 - 300")

Vertical synchronization (max)
0.12 kHz

Vertical synchronization (min)
0.05 kHz

Software

Mac compatibility
Yes

Storage

Card reader integrated
No

Video

Analog signal format system
NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM

Full HD
Yes

Supported graphics resolutions
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)

Supported video modes
480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Weight & dimensions

Depth
329 mm

Height
141 mm

Weight
4.8 kg

Width
420 mm

NEC NP-P554U Standard throw projector 5300 ANSI lumens LCD WUXGA (1920x1200) White
