TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
Roll over image to zoom inClick to Open expanded view
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
Print
Model: ES205GP
EAN: 8885020620948

TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+

Manufacturer:
TP-LINK
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Wall mountable
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 8000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE). Wall mountable
  • 5× 10/100/1000Mbps RJ45 ports (4× 802.3at/af-compliant PoE+)
  • 65W Power Budget, with up to 30W for each PoE port*
  • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
  • Centralized Cloud Management via the web or the Omada app†
  • Up to 250m PoE**, QoS△, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
  • Automatic Loop Prevention, VLAN, and IGMP Snooping
  • Fanless design for silent operation
  • Durable metal casing and desktop/wall mounting design

Product Properties

  • Model
  • ES205GP
  • EAN
  • 8885020620948
  • Bullet points
  • Point
  • 5× 10/100/1000Mbps RJ45 ports (4× 802.3at/af-compliant PoE+)
    65W Power Budget, with up to 30W for each PoE port*
    Automatic Loop Prevention, VLAN, and IGMP Snooping
    Centralized cloud management via the web or the Omada app†
    Durable metal casing and desktop/wall mounting design
    EASY TO USE
    Fanless design for silent operation
  • Certificates
  • Compliance certificates
  • CE, Federal Communications Commission (FCC), RoHS
  • Data transmission
  • Forwarding rate
  • 7.4 Mpps
  • Jumbo frames
  • 15
  • Jumbo frames support
  • Yes
  • MAC address table
  • 8000 entries
  • Packet buffer memory
  • 4 MB
  • Store-and-forward
  • Yes
  • Switching capacity
  • 10 Gbit/s
  • Design
  • LED indicators
  • Yes
  • Product colour
  • Black
  • Reset button
  • Yes
  • Wall mountable
  • Yes
  • Management features
  • Cloud-managed
  • Yes
  • Quality of Service (QoS) support
  • Yes
  • Switch type
  • Managed
  • Network
  • 10G support
  • No
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Flow control support
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3x
  • Port mirroring
  • Yes
  • Virtual LAN features
  • MTU VLAN, Port-based VLAN, Tagged VLAN
  • VLAN support
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Optical fiber
  • Transmission distance (max)
  • 0.25 km
  • Packaging content
  • User guide
  • Yes
  • Packaging data
  • Package type
  • Box
  • Performance
  • Fanless
  • Yes
  • Ports & interfaces
  • Switch Number of Ports
  • 5
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • DC input voltage
  • 53.5 V
  • Power source
  • AC/DC
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet (PoE) ports quantity
  • 4
  • Power over Ethernet (PoE) power per port
  • 30 W
  • Power over Ethernet plus (PoE+) ports quantity
  • 4
  • Total Power over Ethernet (PoE) budget
  • 65 W
  • Security
  • DHCP features
  • DHCP client
  • IGMP snooping
  • Yes
  • Loop protection
  • Yes
  • Weight & dimensions
  • Depth
  • 98 mm
  • Height
  • 25 mm
  • Width
  • 100 mm
