TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
Roll over image to zoom inClick to Open expanded view
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
Print
Model: SG2210XMP-M2
EAN: 4895252504781

TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+

Manufacturer:
TP-LINK
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+, Managed, L2/L2+, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, Wall mountable
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 16000 entries, Switching capacity: 80 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3x. Power connector: AC/DC. Power over Ethernet (PoE). Wall mountable, Rack mounting, Form factor: Desktop/Wall-Mounting
  • 8× 2.5 Gbps 802.3at/af-compliant PoE+ ports
  • 2× 10G SFP+ Slots
  • 160 W total PoE budget with up to 30 W PoE output per port*
  • Centralized cloud management via web or the Omada app†
  • Supports standalone management
  • Static Routing
  • Fanless design for quiet operation
  • Desktop/Wall-Mounting

Product Properties

  • Model
  • SG2210XMP-M2
  • EAN
  • 4895252504781
  • Bullet points
  • Point
  • 160 W total PoE budget with up to 30 W PoE output per port*
    2× 10G SFP+ Slots
    8× 2.5 Gbps 802.3at/af-compliant PoE+ ports
    Centralized cloud management via web or the Omada app†
    Desktop/Wall-Mounting
    Fanless design for quiet operation
    Static Routing
    Supports standalone management
  • Certificates
  • Compliance certificates
  • CE, Federal Communications Commission (FCC), RoHS
  • Data transmission
  • Forwarding rate
  • 59.52 Mpps
  • Jumbo frames
  • 9000
  • Jumbo frames support
  • Yes
  • MAC address table
  • 16000 entries
  • Packet buffer memory
  • 9 MB
  • Static route
  • Yes
  • Switching capacity
  • 80 Gbit/s
  • Design
  • Form factor
  • Desktop/Wall-Mounting
  • LED indicators
  • Yes
  • Product colour
  • Black
  • Rack mounting
  • Yes
  • Reset button
  • Yes
  • Wall mountable
  • Yes
  • Management features
  • ARP inspection
  • Yes
  • Cloud-managed
  • Yes
  • Configuring Location Settings (CLI)
  • Yes
  • MIB support
  • Y
  • Quality of Service (QoS) support
  • Yes
  • Switch layer
  • L2/L2+
  • Switch type
  • Managed
  • System event log
  • Yes
  • Web-based management
  • Yes
  • Multicast features
  • Multicast support
  • Yes
  • Network
  • 10G support
  • No
  • Broadcast storm control
  • Yes
  • Ethernet LAN data rates
  • 10,100,1000,2500 Mbit/s
  • Flow control support
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3x
  • Number of VLANs
  • 4000
  • Port mirroring
  • Yes
  • Rate limiting
  • Yes
  • Spanning tree protocol
  • Yes
  • Virtual LAN features
  • Protocol-based VLAN, Tagged VLAN, Voice VLAN
  • VLAN support
  • Yes
  • Operational conditions
  • Heat dissipation
  • 614.58 BTU/h
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • Quick start guide
  • Yes
  • Ports & interfaces
  • Installed SFP modules quantity
  • 0
  • Installed SFP+ modules quantity
  • 0
  • Power connector
  • AC/DC
  • SFP+ module slots quantity
  • 2
  • Switch Number of Ports
  • 8
  • Switch Port Speed
  • 2.5G Ethernet (100/1000/2500)
  • Power
  • Power consumption (max)
  • 180.1 W
  • Power source
  • AC
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet plus (PoE+) ports quantity
  • 8
  • Total Power over Ethernet (PoE) budget
  • 160 W
  • Security
  • Access Control List (ACL)
  • Yes
  • Authentication
  • MAC-based authentication, Port-based authentication
  • Authentication type
  • RADIUS
  • DHCP features
  • DHCP relay, DHCP server, DHCPv6 client, DHCPv6 snooping
  • IGMP snooping
  • Yes
  • Loop protection
  • Yes
  • Security algorithms
  • SNMP, SNMPv2, SNMPv3
  • Sustainability
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Depth
  • 131 mm
  • Height
  • 35 mm
  • Width
  • 226 mm
