TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point
Roll over image to zoom inClick to Open expanded view
TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point
TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point
TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point
TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point
Print
Model: EAP683 LR
EAN: 4895252506471

TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point

Manufacturer:
TP-LINK
TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point, 2.4 GHz, 5 GHz, 6000 Mbit/s, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, 10,100,1000,2500 Mbit/s
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link Omada AX6000 Ceiling Mount WiFi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 6000 Mbit/s. Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH. Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White
  • Up to 5952 Mbps WiFi 6 Speeds: 1148 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz
  • Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc
  • Integrates with Omada SDN platform for centralized management
  • Advanced Features: Omada Mesh, Seamless Roaming, and more
  • PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter not included)

Product Properties

  • Model
  • EAP683 LR
  • EAN
  • 4895252506471
  • Antenna
  • Antenna direction type
  • Omni-directional
  • Antenna gain level (max)
  • 5 dBi
  • Antenna type
  • Internal
  • Bullet points
  • Point
  • Advanced Features: Omada Mesh, Seamless Roaming, and more
    Integrates with Omada SDN platform for centralized management
    PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter not included)
    Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc
    Up to 5952 Mbps WiFi 6 Speeds: 1148 Mbps on 2.4 GHz + 4804 Mbps on 5 GHz
  • Certificates
  • Compliance certificates
  • CE, RoHS
  • Design
  • LED indicators
  • Yes
  • Placement
  • Ceiling, Wall
  • Product colour
  • White
  • Reset button
  • Yes
  • Features
  • 2.4 GHz
  • Yes
  • 5 GHz
  • Yes
  • 6 GHz
  • No
  • Airtime Fairness (ATF)
  • Yes
  • Automatic channel scanning
  • Yes
  • Automatic channel selection
  • Yes
  • Band steering
  • Yes
  • BeamForming
  • Yes
  • Ethernet LAN data rates
  • 10,100,1000,2500 Mbit/s
  • Fast roaming
  • Yes
  • Frequency band
  • 2.4 - 6 GHz
  • Maximum data transfer rate
  • 6000 Mbit/s
  • Maximum data transfer rate (2.4 GHz)
  • 1148 Mbit/s
  • Maximum data transfer rate (5 GHz)
  • 4804 Mbit/s
  • MIMO
  • Yes
  • MIMO type
  • Multi User MIMO
  • Networking standards
  • IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
  • Number of users
  • 510 user(s)
  • Quality of Service (QoS) support
  • Yes
  • Rate limiting
  • Yes
  • VLAN support
  • Yes
  • Management features
  • Firmware upgradeable
  • Yes
  • Syslog
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • Mounting kit
  • Yes
  • Quantity per pack
  • 1 pc(s)
  • Quick start guide
  • Yes
  • Packaging data
  • Package type
  • Box
  • Ports & interfaces
  • DC-in jack
  • Yes
  • Ethernet LAN (RJ-45) ports
  • 1
  • USB 2.0 ports quantity
  • 0
  • Power
  • DC voltage range
  • 12 V
  • Power over Ethernet (PoE)
  • Yes
  • Security
  • Access Control List (ACL)
  • Yes
  • MAC address filtering
  • Yes
  • Security algorithms
  • HTTPS, SNMP, SNMPv2, SNMPv3, SSH
  • Service Set Identifier (SSID) features
  • Multiple SSIDs
  • Weight & dimensions
  • Depth
  • 220 mm
  • Height
  • 32.5 mm
  • Width
  • 220 mm
