Model: EAP653 UR
EAN: 8885020620573

TP-Link Omada EAP653 UR wireless access point 2976 Mbit/s White Power over Ethernet (PoE)

Manufacturer:
TP-LINK
TP-Link Omada EAP653 UR, 2.4 GHz, 5 GHz, 2976 Mbit/s, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA, WPA2, WPA3, 10,100,1000 Mbit/s
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link Omada EAP653 UR. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2976 Mbit/s. Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA, WPA2, WPA3. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
  • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds
  • High-Efficiency WiFi 6: More connected devices can enjoy faster speeds
  • Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app
  • 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160
  • Seamless Roaming: Video streams and voice calls are unaffected as users move between locations

Product Properties

  • Model
  • EAP653 UR
  • EAN
  • 8885020620573
  • Antenna
  • Antenna type
  • Internal
  • Bullet points
  • Point
  • 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160
    Centralized Cloud Management
    High-Efficiency WiFi 6: More connected devices can enjoy faster speeds
    Seamless Roaming: Video streams and voice calls are unaffected as users move between locations
    Ultra-Fast WiFi 6 Speeds
  • Design
  • LED indicators
  • Yes
  • Placement
  • Ceiling, Wall
  • Product colour
  • White
  • Reset button
  • Yes
  • Features
  • 2.4 GHz
  • Yes
  • 5 GHz
  • Yes
  • 6 GHz
  • No
  • Airtime Fairness (ATF)
  • Yes
  • Automatic channel scanning
  • Yes
  • Automatic channel selection
  • Yes
  • Band steering
  • Yes
  • BeamForming
  • Yes
  • Cabling technology
  • 10/100/1000Base-T(X)
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • Fit AP mode features
  • Mesh networking
  • Flow control support
  • Yes
  • Frequency band
  • 2.4 - 5 GHz
  • Maximum data transfer rate
  • 2976 Mbit/s
  • Maximum data transfer rate (2.4 GHz)
  • 574 Mbit/s
  • Maximum data transfer rate (5 GHz)
  • 2402 Mbit/s
  • MIMO
  • Yes
  • MIMO type
  • Multi User MIMO
  • Networking standards
  • IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h
  • Number of users
  • 250 user(s)
  • Quality of Service (QoS) support
  • Yes
  • Rate limiting
  • Yes
  • Spread spectrum method
  • OFDMA
  • Transmitting power (CE)
  • 27 dBm
  • Transmitting power (FCC)
  • 22 dBm
  • VLAN support
  • Yes
  • Management features
  • Firmware upgradeable
  • Yes
  • Syslog
  • Yes
  • Web-based management
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • Mounting kit
  • Yes
  • Quantity per pack
  • 1 pc(s)
  • Quick start guide
  • Yes
  • Packaging data
  • Package type
  • Box
  • Ports & interfaces
  • DC-in jack
  • Yes
  • Ethernet LAN (RJ-45) ports
  • 1
  • USB 2.0 ports quantity
  • 0
  • Power
  • DC voltage range
  • 12 V
  • Power over Ethernet (PoE)
  • Yes
  • Security
  • MAC address filtering
  • Yes
  • Security algorithms
  • HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA, WPA2, WPA3
  • Weight & dimensions
  • Depth
  • 160 mm
  • Height
  • 33.6 mm
  • Width
  • 160 mm
