Description

TP-Link Omada EAP670. 2.4 GHz, 5 GHz, Maximum data transfer rate: 5400 Mbit/s, Ethernet LAN data rates: 2500 Mbit/s. Power over Ethernet (PoE). Product colour: White

Blazing-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 4804 Mbps on 5 GHz totals 5378 Mbps WiFi speeds.†
High-Efficiency WiFi 6: More connected devices can enjoy faster speeds
Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app
160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.‡
Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.§
Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.§
PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter included) power supply for flexible installations

Product Properties

Manufacturer
TP-LINK

Model
EAP670-KTO

EAN
5056489784196

Antenna

Antenna direction type
Omni-directional

Antenna gain level (max)
5 dBi

Antenna type
Internal

Antennas quantity
6

Bullet points

Point
160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.‡

Blazing-Fast WiFi 6 Speeds

Centralized Cloud Management

High-Efficiency WiFi 6: More connected devices can enjoy faster speeds

Omada Mesh

PoE+ Powered

Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.§

Certificates

Certification
CE, FCC, RoHS

Design

International Protection (IP) code
IP67

LED indicators
Yes

Placement
Ceiling, Wall

Product colour
White

Reset button
Yes

Features

2.4 GHz
Yes

5 GHz
Yes

6 GHz
No

Automatic channel scanning
Yes

Automatic channel selection
Yes

Band steering
Yes

BeamForming
Yes

Ethernet LAN data rates
2500 Mbit/s

Frequency band
2.4 - 5 GHz

Maximum data transfer rate
5400 Mbit/s

Maximum data transfer rate (2.4 GHz)
574 Mbit/s

Maximum data transfer rate (5 GHz)
4804 Mbit/s

MIMO
Yes

MIMO type
Multi User MIMO

Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Number of users
250 user(s)

Quality of Service (QoS) support
Yes

Rate limiting
Yes

Transmitting power (CE)
<20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, band1 & band2, EIRP); <30 dBm(5 GHz, band3, EIRP)

Transmitting power (FCC)
<25 dBm (2.4 GHz); <28 dBm (5 GHz)

VLAN support
No

Wireless isolation
Yes

Management features

Firmware upgradeable
Yes

Web-based management
Yes

Packaging content

Quantity per pack
1 pc(s)

Packaging data

Package depth
304 mm

Package height
82 mm

Package weight
1.32 kg

Package width
302 mm

Power

Input current
1.5 A

Power over Ethernet (PoE)
Yes

Security

Access Control List (ACL)
Yes

Number of SSID supported
16

Remote Authentication Dial-In User Service (RADIUS)
Yes

Service Set Identifier (SSID) features
Multiple SSIDs

Weight & dimensions

Depth
243 mm

Height
64 mm

Width
243 mm
