Description

TP-Link Omada Multi-Gigabit VPN Router. Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x, Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Supported network protocols: TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP. Security algorithms: 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3. Compliance certificates: CE, Federal Communications Commission (FCC), RoHS. Flash memory: 128 MB, Internal memory: 1000 MB, Internal memory type: DDR4

Two 2.5G Ports: 1× 2.5G WAN and 1× 2.5G WAN/LAN ports provide high-bandwidth aggregation connectivity
Up to 6 WAN Ports: 2.5G RJ45, gigabit Fiber, and gigabit RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband
Highly Secure VPN: Enterprise-standard SSL/IPSec/GER§/PPTP/L2TP VPN & OpenVPN are ideal for use across multiple branches and for WFH
Integrated into Omada SDN: Supports Zero-Touch Provisioning (ZTP),** Centralized Cloud Management, Intelligent Monitoring, and more
Centralized Management: Cloud access and Omada app provide the utmost in management convenience
Extensive Security Features: Protect your network and data with advanced firewall policies, DoS defense, IP/MAC/URL filtering, and more security functions

Product Properties

Manufacturer
TP-LINK

Model
ER707-M2

EAN
4895252500745

Bullet points

Point
Centralized Management: Cloud access and Omada app provide the utmost in management convenience

Extensive Security Features

Highly Secure VPN

Integrated into Omada SDN

Two 2.5G Ports

Up to 6 WAN Ports

Certificates

Compliance certificates
CE, Federal Communications Commission (FCC), RoHS

Sustainability compliance
Yes

Design

Housing material
Steel

LED indicators
LAN, Link, Power, Speed, System, USB, WAN

Product colour
Black

Wall mountable
Yes

Features

Flash memory
128 MB

Internal memory
1000 MB

Internal memory type
DDR4

Linux operating systems supported
Yes

Mac operating systems supported
Yes

Windows operating systems supported
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP

Management features

Reset button
Yes

Universal Plug and Play (UPnP)
Yes

Web-based management
Yes

Network

Ethernet interface type
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet

Ethernet LAN data rates
10,100,1000,2500 Mbit/s

Networking standards
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x

Policy-based routing
Yes

Static route
Yes

Throughput
1.44 Gbit/s

VLAN support
Yes

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging content

AC adapter included
Yes

Quick installation guide
Yes

Packaging data

Package depth
323 mm

Package height
73 mm

Package weight
1.1 kg

Package width
242 mm

Ports & interfaces

Ethernet LAN (RJ-45) ports
6

Installed SFP modules quantity
1

USB ports quantity
1

USB version
2.0

WAN ports quantity
1

WAN/Ethernet LAN ports quantity
6

Power

Output current
1.5 A

Output voltage
12 V

Power source type
DC

Protocols

DHCP client
Yes

DHCP server
Yes

DMZ support
Yes

Supported network protocols
TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP

Security

Access Control List (ACL)
Yes

ICMP attack prevention
Yes

Network address translation (NAT)
Yes

Security algorithms
3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3

System event log
Yes

URL filtering
Yes

VPN tunnels quantity
66

WAN connection

Ethernet WAN
Yes

SFP WAN
Yes

Weight & dimensions

Depth
131 mm

Height
35 mm

Width
226 mm
