- Brightness(Typ.): 400nit (APL 25%, Without Glass)
- Transparency(Typ.) : 38%
- Bezel : 7.9 mm (T/B/L), 121.7 mm (B)
- Interface : HDMI/DP/USB(2)/ RS232C/ RJ45/ Audio/ IR
PANEL
-
- Screen Size
- 55"
- Panel Technology
- OLED
-
- Native Resolution
- 1,920 x 1,080 (FHD)
- Brightness
- 150/400nit (APL 100%/25%, Without Glass)
-
- Contrast Ratio
- 150,000 : 1
- Dynamic CR
- No
-
- Color gamut
- BT709 120 %
- Viewing Angle (H x V)
- 178 x 178
-
- Color Depth
- 10bit(R), 1.07Bilion colors
- Response Time
- 1ms (G to G), 8ms (MPRT)
-
- Surface Treatment (Haze)
- Hard coating (2H)
- Operation Hours (Hours / Day)
- 18 / 7 (Moving Content Only)
CONNECTIVITY
-
- Input
- HDMI (1, HDCP 1.4), DP (1, HDCP 1.3), RS232C IN , RJ45(LAN), IR IN (1,External IR Receiver,) USB2.0 Type A(2)
- Output
- DP Out, Audio Out, RS232C OUT (1, w/ IR out), RJ45(LAN)
MECHANICAL SPECIFICATION
-
- Bezel Width
- T/R/L/B : 7.9/7.9/7.9/121.7mm
- Weight (Head)
- 11.6Kg (Head), 3.4Kg (Signage Box)
-
- Monitor Dimension (W x H x D)
- 1225.5 x 810.1 x 4.9mm (Head)
782.8 x 238.4 x 34.7mm (Signage Box)
- VESA™ Standard Mount Interface
- No
-
- Protection Glass
- Depth 3.0 mm , Tempered / Chemical Strengthening, Anti-Reflective (Film), Shatter-Proof
FEATURE
-
- HW
- Temperature Sensor
- SW
- Fail over, Screen Rotation, External Input Rotation, Tile Mode Setting,
ENVIRONMENT CONDITIONS
-
- Operation Temperature
- 0 °C to 40 °C
- Operation Humidity
- 10 % to 80 %
POWER
-
- Power Supply
- AC 100-240V~, 50/60Hz
- Power Type
- Built-In Power
POWER CONSUMPTION
-
- Typ.
- 250W
- Max.
- 280W
-
- Typ. / Max.
- 250 W / 280 W
- BTU (British Thermal Unit)
- 853.03 BTU/Hr(Typ.), 955.39 BTU/Hr(Max)
SOUND
CERTIFICATION
-
- Safety
- IEC 60950-1 / EN 60950-1 / UL 60950-1
- EMC
- FCC Class "A" / CE / KC
ACCESSORY
-
- Basic
- Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables(3000mmx4ea/3000mmx2ea) for connection between panel and Signage Box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Screw(M4xL22,12EA / M4 Nut 12EA / M3xL5.5,8EA / M3xL3.5, 20EA), Shield Cover Assy', Rubber Damper 4EA, MCX cable Holder 4ea
- Optional
- Stand (ACC-S-EW5F, 2 Pole)
|
