Cisco Meraki MS130R Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Aluminium
Roll over image to zoom inClick to Open expanded view
Print
Model: MS130R-8P-HW

Cisco Meraki MS130R Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Aluminium

Manufacturer:
Cisco
Cisco Meraki MS130R, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Please log in to see your price
Related products

Description

Cisco Meraki MS130R. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Networking standards: IEEE 802.11w, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
  • Protective ground connection design
  • Flexible powering options: terminal block and DC power jack
  • Flexbile mounting options: rack, wall, and DIN rail mounting options
  • Remote packet capture tools via the Meraki dashboard
  • IPv4/6 ACL support
  • Review, schedule, and update firmware for all your switches in one location
  • Flexibility and ecosystem extensibility​ with Meraki API and ecosystems
  • Layer 7 visibility and built-in application layer visbility
  • Rich telemetry source and endpoint modeling
  • Visualize the connection path of each endpoint to the internet
  • Voice and video QoS
  • Non-blocking switch fabric

Product Properties

  • Model
  • MS130R-8P-HW
  • Bullet points
  • Point
  • Flexbile mounting options: rack, wall, and DIN rail mounting options
    Flexibility and ecosystem extensibility​ with Meraki API and ecosystems
    Flexible powering options: terminal block and DC power jack
    IPv4/6 ACL support
    Layer 7 visibility and built-in application layer visbility
    Non-blocking switch fabric
    Protective ground connection design
    Remote packet capture tools via the Meraki dashboard
    Review, schedule, and update firmware for all your switches in one location
    Rich telemetry source and endpoint modeling
    Visualize the connection path of each endpoint to the internet
    Voice and video QoS
  • Certificates
  • Certification
  • CSA-US, FCC, IC, CE, RCM, RoHS
  • Data transmission
  • Jumbo frames support
  • Yes
  • Static route
  • Yes
  • Design
  • Form factor
  • 1U
  • Product colour
  • Aluminium
  • Rack mounting
  • Yes
  • Stackable
  • Yes
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Switch type
  • Managed
  • System event log
  • Yes
  • Web-based management
  • Yes
  • Multicast features
  • Multicast support
  • Yes
  • Network
  • 10G support
  • No
  • Broadcast storm control
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.11w, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad
  • Port mirroring
  • Yes
  • Spanning tree protocol
  • Yes
  • VLAN support
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 5 - 95%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Packaging data
  • Screws included
  • Yes
  • Performance
  • Firmware upgradeable
  • Yes
  • Physical stacking (units)
  • 8
  • Ports & interfaces
  • Console port
  • RJ-45
  • Switch Number of Ports
  • 8
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • AC input frequency
  • 47/63 Hz
  • AC input voltage
  • 100 - 240 V
  • Redundant power supply (RPS) support
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Protocols
  • Switching protocols
  • LLDP, CDP, RSTP, STP
  • Security
  • Access Control List (ACL)
  • Yes
  • Authentication
  • MAC-based authentication
  • Authentication type
  • RADIUS
  • BPDU filtering/protection
  • Yes
  • DHCP features
  • DHCP snooping, DHCP relay, DHCP client
  • IGMP snooping
  • Yes
  • Password protection
  • Yes
  • Security algorithms
  • SNMP
