Model: CP-9020132-UK
EAN: 843591091213

Corsair TX650M power supply unit 650 W 20+4 pin ATX ATX Black

Manufacturer:
Corsair
Corsair TX650M, 650 W, 100 - 240 V, 47 - 63 Hz, 10 A, Active, 130 W
Please log in to see your price
Related products

Description

Corsair TX650M. Total power: 650 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 500,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, Certification: FCC, ICES, CE, UL, cUL, RCM, TÜV, CB, CCC, BSMI, EAC, WEEE, KC

Product Properties

  • Model
  • CP-9020132-UK
  • EAN
  • 843591091213
  • Certificates
  • Certification
  • FCC, ICES, CE, UL, cUL, RCM, TÜV, CB, CCC, BSMI, EAC, WEEE, KC
  • Compliance certificates
  • RoHS
  • Design
  • Cooling type
  • Active
  • Fan diameter
  • 12 cm
  • Fan location
  • Top
  • Fan speed
  • 1546
  • Number of fans
  • 1 fan(s)
  • On/off switch
  • Yes
  • Product colour
  • Black
  • Operational conditions
  • Operating temperature (T-T)
  • 0 - 50 °C
  • Other features
  • Noise level (full-load mode, 100%)
  • 33.1 dB
  • Noise level (quiet mode, 50%)
  • 15.8 dB
  • Noise level (silent mode, <30%)
  • 6 dB
  • Warranty card
  • Yes
  • Packaging data
  • Manual
  • Yes
  • Package type
  • Box
  • Performance
  • 80 PLUS certification
  • 80 PLUS Gold
  • ATX version
  • 2.32
  • Bearing technology
  • Rifle
  • EPS version
  • 2.92
  • Mean time between failures (MTBF)
  • 100000 h
  • Power supply unit (PSU) form factor
  • ATX
  • Purpose
  • PC
  • Ports & interfaces
  • Cabling type
  • Semi-Modular
  • EPS power connector (8-pin)
  • Yes
  • Floppy disk drive cable length
  • 10.1 cm
  • Floppy disk drive connector
  • Yes
  • Floppy drive power connector
  • 1
  • Motherboard power cable length
  • 61 cm
  • Motherboard power connector
  • 20+4 pin ATX
  • Number of SATA power connectors
  • 6
  • PCI Express connector
  • Yes
  • PCI Express power cable length
  • 60 cm
  • PCI Express power connectors (6+2 pin)
  • 4
  • Peripheral (Molex) power cable length
  • 450,550,650,750 mm
  • Peripheral (Molex) power connectors (4-pin)
  • 4
  • SATA power cable length
  • 500,600 mm
  • Power
  • AC input frequency
  • 47 - 63 Hz
  • AC input voltage
  • 100 - 240 V
  • Combined power (+12V)
  • 612 W
  • Combined power (+3.3V)
  • 130 W
  • Combined power (+5V)
  • 130 W
  • Combined power (+5Vsb)
  • 15 W
  • Combined power (-12V)
  • 9.6 W
  • Hold time
  • 16 ms
  • Input current
  • 10 A
  • Max output current (+12V)
  • 51 A
  • Max output current (+3.3V)
  • 25 A
  • Max output current (+5V)
  • 25 A
  • Max output current (+5Vsb)
  • 3 A
  • Max output current (-12V)
  • 0.8 A
  • Power factor
  • 0.99
  • Power Factor Correction (PFC) type
  • Active
  • Power protection features
  • Over power, Over voltage, Overheating, Short circuit, Under voltage
  • Total power
  • 650 W
  • Technical details
  • Sustainability certificates
  • ENERGY STAR
  • Weight & dimensions
  • Depth
  • 140 mm
  • Height
  • 86 mm
  • Weight
  • 1.7 kg
  • Width
  • 150 mm
