Eaton 5S700IBS uninterruptible power supply (UPS) Line-Interactive 1.5 kVA 900 W 6 AC outlet(s)
Roll over image to zoom inClick to Open expanded view
Model: 5S700IBS
EAN: 3553340620188

Eaton 5S700IBS uninterruptible power supply (UPS) Line-Interactive 1.5 kVA 900 W 6 AC outlet(s)

Manufacturer:
Eaton
Eaton 5S700IBS, Line-Interactive, 1.5 kVA, 900 W, 175 V, 275 V, 46/70 Hz
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Eaton 5S700IBS. UPS topology: Line-Interactive, Output power capacity: 1.5 kVA, Output power: 900 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 7 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black. Compliance certificates: CE, Certification: IEC/EN 62040-1 IEC/EN 62040-2 EAC

Product Properties

  • Model
  • 5S700IBS
  • EAN
  • 3553340620188
  • Battery
  • Automatic battery test
  • Yes
  • Battery capacity
  • 7 Ah
  • Battery technology
  • Sealed Lead Acid (VRLA)
  • Battery voltage
  • 12 V
  • Typical backup time at full load
  • 2 min
  • Certificates
  • Certification
  • IEC/EN 62040-1 IEC/EN 62040-2 EAC
  • Compliance certificates
  • CE
  • Design
  • Form factor
  • Tower
  • LED indicators
  • Yes
  • Product colour
  • Black
  • Features
  • Automatic Voltage Regulation (AVR)
  • Yes
  • Efficiency
  • 97%
  • Input frequency
  • 46/70 Hz
  • Input operation voltage (max)
  • 275 V
  • Input operation voltage (min)
  • 175 V
  • Noise level
  • 25 dB
  • Number of input phases
  • 1
  • Number of output phases
  • 1
  • Output frequency
  • 50/60 Hz
  • Output operation voltage (max)
  • 276 V
  • Output operation voltage (min)
  • 184 V
  • Output power
  • 900 W
  • Output power capacity
  • 1.5 kVA
  • Output power factor
  • 0.6
  • Power factor
  • 0.6
  • Power protection features
  • Overdischarge
  • Surge protection
  • Yes
  • UPS topology
  • Line-Interactive
  • Operational conditions
  • Operating altitude
  • 0 - 2000 m
  • Operating relative humidity (H-H)
  • 0 - 85%
  • Operating temperature (T-T)
  • 0 - 35 °C
  • Packaging content
  • Cables included
  • Input power cable, USB cable
  • Ports & interfaces
  • AC outlet types
  • C13 coupler
  • AC outlets quantity
  • 6 AC outlet(s)
  • Power plug
  • C14 coupler
  • Serial interface
  • No
  • USB port
  • Yes
  • Sustainability
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Depth
  • 87 mm
  • Height
  • 250 mm
  • Weight
  • 7.1 kg
  • Width
  • 260 mm
