Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Roll over image to zoom inClick to Open expanded view
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)
Print
Model: 5SC750IBS
EAN: 3553340620409

Eaton 5SC750IBS uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 525 W 6 AC outlet(s)

Manufacturer:
Eaton
Eaton 5SC750IBS, Line-Interactive, 0.75 kVA, 525 W, Sine, 184 V, 276 V
Please log in to see your price
Related products

Description

Eaton 5SC750IBS. UPS topology: Line-Interactive, Output power capacity: 0.75 kVA, Output power: 525 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 7 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, Display type: LCD. Compliance certificates: CE, Certification: cTUVus IEC/EN 62040-1 UL 1778 IEC/EN 62040-2 EAC

Product Properties

  • Model
  • 5SC750IBS
  • EAN
  • 3553340620409
  • Battery
  • Automatic battery test
  • Yes
  • Battery capacity
  • 7 Ah
  • Battery technology
  • Sealed Lead Acid (VRLA)
  • Battery voltage
  • 12 V
  • Hot-swap battery
  • Yes
  • Number of batteries supported
  • 2
  • Typical backup time at full load
  • 5 min
  • Certificates
  • Certification
  • cTUVus IEC/EN 62040-1 UL 1778 IEC/EN 62040-2 EAC
  • Compliance certificates
  • CE
  • Design
  • Display type
  • LCD
  • Form factor
  • Tower
  • Product colour
  • Black
  • Features
  • Automatic Voltage Regulation (AVR)
  • Yes
  • Efficiency
  • 96%
  • Input frequency
  • 45/65 Hz
  • Input operation voltage (max)
  • 276 V
  • Input operation voltage (min)
  • 184 V
  • Noise level
  • 40 dB
  • Number of input phases
  • 1
  • Number of output phases
  • 1
  • Output frequency
  • 50/60 Hz
  • Output operation voltage (max)
  • 240 V
  • Output operation voltage (min)
  • 220 V
  • Output power
  • 525 W
  • Output power capacity
  • 0.75 kVA
  • Output power factor
  • 0.7
  • Power factor
  • 0.7
  • Power protection features
  • Overdischarge
  • UPS topology
  • Line-Interactive
  • Waveform
  • Sine
  • Operational conditions
  • Operating altitude
  • 0 - 2000 m
  • Operating relative humidity (H-H)
  • 0 - 90%
  • Packaging content
  • Cables included
  • Input power cable, Serial, USB cable
  • Quick installation guide
  • Yes
  • Rack mount kit
  • No
  • Ports & interfaces
  • AC outlet types
  • C13 coupler
  • AC outlets quantity
  • 6 AC outlet(s)
  • Power plug
  • C14 coupler
  • Serial interface
  • Yes
  • Serial interface type
  • RS-232
  • Serial ports quantity
  • 1
  • USB 2.0 ports quantity
  • 1
  • USB port
  • Yes
  • Sustainability
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Depth
  • 480 mm
  • Height
  • 310 mm
  • Weight
  • 11.5 kg
  • Width
  • 240 mm
