Description

Epson EB-L265F. Projector brightness: 4600 ANSI lumens, Projection technology: 3LCD, Projector native resolution: 1080p (1920x1080). Light source type: Laser, Service life of light source: 20000 h, Service life of light source (economic mode): 30000 h. Focus: Manual, Focal length range: 18.2 - 29.1 mm, Aperture range (F-F): 1.51 - 1.77. Video processing: 10 bit, Video colour modes: Blackboard, Cinema, Dynamic, Multi-projection, Presentation, sRGB. Serial interface type: RS-232C, Service port type: USB Type-B

Experiential signage solution: Large, bright display for signage, or project onto 3D objects
Up to 310-inch display: Full HD resolution, 4,600 lumen brightness and 3LCD technology
Installation flexibility: Wall, ceiling, floor, or lighting track, with 360 degree rotation
Cost effective: 20,000 hours maintenance free - 5 year warranty
Flexible playback: Play content directly from USB stick or Miracast

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Product Properties

Manufacturer
Epson

Model
V11HA72180

EAN
8715946715490

Bullet points

Point
Cost effective: 20,000 hours maintenance free - 5 year warranty

Experiential signage solution: Large, bright display for signage, or project onto 3D objects

Flexible playback: Play content directly from USB stick or Miracast

Installation flexibility: Wall, ceiling, floor, or lighting track, with 360 degree rotation

Up to 310-inch display: Full HD resolution, 4,600 lumen brightness and 3LCD technology

Design

Cable lock slot
Yes

Cable lock slot type
Kensington

Market positioning
Presentation

Placement
Ceiling, Floor, Wall

Product colour
Black

Display

Built-in display
No

Features

Country of origin
Philippines

HDCP
Yes

Interactive
No

Noise level
37 dB

Noise level (economic mode)
27 dB

Password protection
Yes

Lens system

Aperture range (F-F)
1.51 - 1.77

Focal length range
18.2 - 29.1 mm

Focus
Manual

Throw ratio
1.32 - 2.12:1

Zoom capability
Yes

Zoom ratio
1:1.62

Zoom type
Manual

Light source

Light source type
Laser

Service life of light source
20000 h

Service life of light source (economic mode)
30000 h

Logistics data

Pallet gross height
2.24 m

Pallet gross length
120 cm

Pallet gross width
80 cm

Pallet height (UK)
2.24 m

Pallet length (UK)
120 cm

Products per pallet
22 pc(s)

Products per pallet (UK)
44 pc(s)

Products per pallet layer
2 pc(s)

Products per pallet layer (UK)
4 pc(s)

Quantity per pack
1 pc(s)

Multimedia

Built-in speaker(s)
Yes

RMS rated power
16 W

Network

Ethernet LAN
Yes

Smart TV
No

Wi-Fi
Yes

Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Operational conditions

Operating relative humidity (H-H)
20 - 80%

Storage relative humidity (H-H)
10 - 90%

Storage temperature (T-T)
-10 - 60 °C

Other features

Box contents
Cable cover, HDMI Cable, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty document

Control panel
0.62 inch with C2 Fine

Interface
USB 2.0-A, USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, Composite in, Miracast, Jack plug out, Jack plug in (2x), HDMI (HDCP 2.3) (2x)

Option type
Air filter, Ceiling mount, Connection and control box, Document camera, External Speaker, Safety wire set, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01

Security features
Kensington lock, Security bar, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection

Supported network protocols
HTTPS, IPv6, SNMP, ESC/VP.net, PJLink

Packaging content

Batteries included
Yes

Bundled software
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management

Cables included
AC, HDMI

Remote control included
Yes

Ports & interfaces

Component video (YPbPr/YCbCr) in
0

Composite video in
1

DVI port
No

HDMI ports
2

Headphone outputs
3

Serial interface type
RS-232C

Service port type
USB Type-B

USB 2.0 ports quantity
1

VGA (D-Sub) ports quantity
3

Power

AC input frequency
50 - 60 Hz

AC input voltage
220 - 240 V

Power consumption (economy mode)
144 W

Power consumption (typical)
199 W

Power source
AC

Projector

Contrast ratio (dynamic)
5000000:1

Contrast ratio (typical)
2500000:1

Keystone correction, horizontal
±30°

Keystone correction, vertical
±30°

Matrix size
1.57 cm (0.62")

Native aspect ratio
16:9

Number of colours
1.07 billion colours

Projection technology
3LCD

Projector brightness
4600 ANSI lumens

Projector brightness (economic mode)
3200 ANSI lumens

Projector native resolution
1080p (1920x1080)

Screen size compatibility
787.4 - 7874 mm (31 - 310")

Smart projector
No

Vertical scan range
192 - 240 Hz

Storage

Card reader integrated
No

Technical details

Mobile app support
Yes

Other features
A/V mute, Arc Correction, Auto Power On, Auto source search, Automatic keystone correction, Built-in speaker, CEC compatible, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen, Horizontal and vertical keystone correction, Long light source life, OSD copy function, PC Free, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Super resolution, Web Control, Web Remote, Wireless LAN capable, iProjection App

Video

Analog signal format system
Not supported

Full HD
Yes

Video colour modes
Blackboard, Cinema, Dynamic, Multi-projection, Presentation, sRGB

Video processing
10 bit

Weight & dimensions

Package depth
490 mm

Package height
190 mm

Package weight
6.29 kg

Package width
405 mm

Weight
4.2 kg
