Description

Epson EB-L720U. Projector brightness: 7000 ANSI lumens, Projection technology: 3LCD, Projector native resolution: WUXGA (1920x1200). Light source type: Laser, Service life of light source: 20000 h, Service life of light source (economic mode): 30000 h. Focus: Manual, Focal length range: 20 - 31.8 mm, Aperture range (F-F): 1.5 - 1.7. Video processing: 10 bit, Video colour modes: Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode. Serial interface type: RS-232C, HDMI connector type: Full-size

High brightness, scalable size: Provides 7,000 lumens high-brightness display at up to 500"
Premium display features: Full HD, 4K support, edge-blending and geometric correction
Unrestricted viewing: Free from pixilation, glare, fingerprints and a central bevel
Social distancing support: Scalable display meets the needs of every audience configuration
Plug, click and collaborate: Collaborate using Epson’s wireless presentation system - ELPWP10

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Product Properties

Manufacturer
Epson

Model
V11HA44040

EAN
8715946695587

Bullet points

Point
High brightness, scalable size: Provides 7,000 lumens high-brightness display at up to 500"

Plug, click and collaborate: Collaborate using Epson’s wireless presentation system - ELPWP10

Premium display features: Full HD, 4K support, edge-blending and geometric correction

Social distancing support: Scalable display meets the needs of every audience configuration

Unrestricted viewing: Free from pixilation, glare, fingerprints and a central bevel

Design

Cable lock slot
Yes

Cable lock slot type
Kensington

Placement
Ceiling, Desktop, Floor, Wall

Product colour
White

Product type
Standard throw projector

Display

Built-in display
No

Features

Country of origin
China

Interactive
No

Noise level
39 dB

Noise level (economic mode)
27 dB

Lens system

Aperture range (F-F)
1.5 - 1.7

Focal length range
20 - 31.8 mm

Focus
Manual

Offset
27%

Throw ratio
1.35 - 2.20:1

Zoom capability
Yes

Zoom ratio
1.6:1

Zoom type
Manual

Light source

Light source type
Laser

Service life of light source
20000 h

Service life of light source (economic mode)
30000 h

Logistics data

Harmonized System (HS) code
85286200

Pallet gross weight
0 g

Pallet weight (UK)
0 g

Products per pallet
14 pc(s)

Products per pallet (UK)
14 pc(s)

Quantity per pack
1 pc(s)

Multimedia

Built-in speaker(s)
Yes

Number of built-in speakers
1

RMS rated power
10 W

Network

Ethernet LAN
Yes

Ethernet LAN (RJ-45) ports
1

Ethernet LAN data rates
10,100,1000 Mbit/s

Smart TV
No

Wi-Fi
No

Operational conditions

Operating relative humidity (H-H)
20 - 80%

Storage relative humidity (H-H)
10 - 90%

Storage temperature (T-T)
-10 - 60 °C

Packaging content

Batteries included
Yes

Bundled software
EasyMP Multi PC Projection

Cables included
AC, HDMI

Manual
Yes

Remote control included
Yes

Warranty card
Yes

WLAN adapter included
Yes

Ports & interfaces

Audio (L/R) in
0

Component video (YPbPr/YCbCr) in
0

Composite video in
0

DVI port
No

HDBaseT port
Yes

HDMI connector type
Full-size

HDMI ports
2

PC Audio in
Yes

PC Audio out
Yes

Serial interface type
RS-232C

USB 2.0 ports quantity
1

USB 2.0 Type-B ports quantity
1

VGA (D-Sub) ports quantity
3

Power

AC input frequency
50 - 60 Hz

AC input voltage
100-240 V

Power consumption (economy mode)
258 W

Power consumption (standby)
0.3 W

Power consumption (typical)
345 W

Power source
AC

Projector

Contrast ratio (typical)
2500000:1

Keystone correction, horizontal
-30 - 30°

Keystone correction, vertical
-30 - 30°

Matrix size
1.7 cm (0.67")

Native aspect ratio
16:10

Number of colours
1.07 billion colours

Projection technology
3LCD

Projector brightness
7000 ANSI lumens

Projector brightness (economic mode)
4900 ANSI lumens

Projector native resolution
WUXGA (1920x1200)

Screen size compatibility
1270 - 12700 mm (50 - 500")

Vertical scan range
192 - 240 Hz

Software

Software support
via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
