Intel NUC 13 Pro Mini PC NUC13ANKi70QC Intel® Core™ i7 i7-1360P 16 GB DDR4-SDRAM 512 GB SSD Windows 11 Pro UCFF Black
Roll over image to zoom inClick to Open expanded view
Print
Model: 90AB3ANK-MR8A30
EAN: 5032037267588

Intel NUC 13 Pro Mini PC NUC13ANKi70QC Intel® Core™ i7 i7-1360P 16 GB DDR4-SDRAM 512 GB SSD Windows 11 Pro UCFF Black

Manufacturer:
Intel
Intel NUC 13 Pro Mini PC NUC13ANKi70QC, Intel® Core™ i7, i7-1360P, 16 GB, 512 GB, Windows 11 Pro, 64-bit
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Intel NUC 13 Pro Mini PC NUC13ANKi70QC. Processor family: Intel® Core™ i7, Processor model: i7-1360P. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 3200 MHz. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel Iris Xe Graphics. Wi-Fi. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 120 W. Chassis type: UCFF. Product type: Mini PC. Product colour: Black

Product Properties

  • Model
  • 90AB3ANK-MR8A30
  • EAN
  • 5032037267588
  • Design
  • Chassis type
  • UCFF
  • Product colour
  • Black
  • Product family
  • Intel NUC
  • Display
  • Display included
  • No
  • Graphics
  • Discrete graphics card
  • No
  • Discrete graphics card model
  • Not available
  • On-board GPU manufacturer
  • Intel
  • On-board graphics card
  • No
  • On-board graphics card family
  • Intel Iris Xe Graphics
  • On-board graphics card model
  • Intel Iris Xe Graphics
  • Logistics data
  • Harmonized System (HS) code
  • 8471500150
  • Memory
  • ECC
  • No
  • Internal memory type
  • DDR4-SDRAM
  • Memory channels
  • Dual-channel
  • Memory clock speed
  • 3200 MHz
  • Memory Installed
  • 16 GB
  • Memory layout (slots x size)
  • 2 x 8 GB
  • Memory Slot Support
  • 64 GB
  • Memory slots
  • 2x SO-DIMM
  • Non-ECC
  • Yes
  • Number of DIMM slots
  • 2
  • Supported memory types
  • DDR4-SDRAM
  • Network
  • Antenna type
  • 2x2
  • Bluetooth
  • Yes
  • Bluetooth version
  • 5.3
  • Ethernet LAN
  • Yes
  • Ethernet LAN data rates
  • 2500 Mbit/s
  • LAN controller
  • Intel I226-V
  • Top Wi-Fi standard
  • Wi-Fi 6E (802.11ax)
  • Wi-Fi
  • Yes
  • Wi-Fi standards
  • Wi-Fi 6E (802.11ax)
  • WLAN controller manufacturer
  • Intel
  • WLAN controller model
  • Intel Wi-Fi 6E AX211
  • Other features
  • Additional headers
  • Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector
  • ARK ID
  • 233109
  • Commodity Classification Automated Tracking System (CCATS)
  • G157815L2
  • Cooling type
  • Active
  • Export Control Classification Number (ECCN)
  • 5A992C
  • Graphics card family
  • Intel
  • Maximum resolution
  • 7680 x 4320 pixels
  • Number of displays supported
  • 4
  • Number of M.2 (M) slots
  • 1
  • Power supply type
  • External AC adapter
  • USB ports quantity
  • 4
  • Performance
  • Audio output channels
  • 7.1 channels
  • Built-in speaker(s)
  • No
  • Market positioning
  • Business
  • Motherboard form factor
  • UCFF
  • Password protection
  • Yes
  • Product type
  • Mini PC
  • Status
  • Launched
  • Trusted Platform Module (TPM)
  • Yes
  • Trusted Platform Module (TPM) version
  • 2.0
  • Ports & interfaces
  • Combo headphone/mic port
  • Yes
  • DC-in jack
  • Yes
  • DisplayPorts quantity
  • 1
  • Ethernet LAN (RJ-45) ports
  • 1
  • HDMI ports
  • 1
  • HDMI version
  • 2.1
  • Intel® Thunderbolt 4
  • Yes
  • M.2 card slot (storage)
  • 2280 NVMe (M); 2242 SATA (B)
  • M.2 card slot (wireless)
  • 2230 (E-key) (E)
  • Serial port via internal header
  • No
  • Thunderbolt 3 ports quantity
  • 0
  • Thunderbolt 4 ports quantity
  • 2
  • USB 2.0 ports quantity
  • 1
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
  • 3
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
  • 0
  • USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
  • 0
  • USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
  • 0
  • VGA (D-Sub) ports quantity
  • 0
  • Power
  • DC input voltage
  • 12 - 20 V
  • Power supply
  • 120 W
  • Processor
  • Configurable TDP-down
  • 20 W
  • Efficient cores
  • 8
  • Efficient-core Max Turbo Frequency
  • 3.7 GHz
  • Maximum turbo power
  • 64 W
  • Memory types supported by processor
  • DDR4-SDRAM
  • Number of Cores
  • 12
  • Number of processors installed
  • 1
  • PCI Express slots version
  • 4.0
  • Performance cores
  • 4
  • Performance-core Max Turbo Frequency
  • 5 GHz
  • Processor
  • i7-1360P
  • Processor base power
  • 28 W
  • Processor boost frequency
  • 5 GHz
  • Processor cache
  • 18 MB
  • Processor cache type
  • Smart Cache
  • Processor codename
  • Raptor Lake
  • Processor family
  • Intel® Core™ i7
  • Processor generation
  • 13th gen Intel® Core™ i7
  • Processor manufacturer
  • Intel
  • Processor threads
  • 16
  • Processor special features
  • CPU configuration (max)
  • 1
  • Embedded options available
  • No
  • Execute Disable Bit
  • Yes
  • Intel Flex Memory Access
  • Yes
  • Intel Trusted Execution Technology
  • Yes
  • Intel Virtualization Technology (VT-x)
  • Yes
  • Intel Virtualization Technology for Directed I/O (VT-d)
  • Yes
  • Intel VT-x with Extended Page Tables (EPT)
  • Yes
  • Intel® AES New Instructions (Intel® AES-NI)
  • Yes
  • Intel® High Definition Audio (Intel® HD Audio)
  • Yes
  • Intel® Optane™ Memory Ready
  • No
  • Intel® Platform Trust Technology (Intel® PTT)
  • Yes
  • Software
  • Compatible operating systems
  • Windows 10 IoT Enterprise*|Ubuntu*|Linux*
  • Operating system architecture
  • 64-bit
  • Operating system installed
  • Windows 11 Pro
  • Storage
  • Card reader integrated
  • No
  • Number of SSDs installed
  • 1
  • Number of storage drives installed
  • 1
  • Number of storage drives supported
  • 2
  • NVMe
  • Yes
  • Optical drive type
  • No
  • SSD capacity
  • 512 GB
  • SSD form factor
  • M.2
  • SSD interface
  • PCI Express 4.0
  • Storage Capacity
  • 512 GB
  • Storage type
  • SSD
  • Total SSDs capacity
  • 512 GB
  • Weight & dimensions
  • Depth
  • 112 mm
  • Height
  • 37 mm
  • Width
  • 117 mm
