LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
Roll over image to zoom inClick to Open expanded view
LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7
Print
Model: 86TR3PJ

LG 86TR3PJ Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 390 cd/m² 4K Ultra HD Black Touchscreen Built-in processor 16/7

Manufacturer:
LG
LG 86TR3PJ, Digital signage flat panel, 2.18 m (86"), LED, 3840 x 2160 pixels, Wi-Fi, 16/7
Please log in to see your price
Related products

Description

LG 86TR3PJ. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 390 cd/m², HD type: 4K Ultra HD, Touchscreen. Wi-Fi. Operating hours (hours/days): 16/7. Product colour: Black
  • Brightness : 390 nit (w/o Glass, Typ.)
  • Multi Touch Point : 20 Points (Max.)
  • Interface : HDMI, RGB, Audio In, RS-232C In, RJ45, USB 3.0 Type A, USB 2.0 Type A, USB Type-C, Audio Out / Optical Output, Touch USB

Product Properties

  • Manufacturer
  • LG
  • Model
  • 86TR3PJ
  • Audio
  • Built-in speaker(s)
  • Yes
  • Number of built-in speakers
  • 2
  • RMS rated power
  • 24 W
  • Bullet points
  • Point
  • Brightness : 390 nit (w/o Glass, Typ.)
    Interface
    Multi Touch Point : 20 Points (Max.)
  • Computer system
  • Built-in processor
  • Yes
  • Computer system
  • Yes
  • Internal memory
  • 32 GB
  • On-board graphics card model
  • ARM Mali-G51
  • Processor cores
  • 4
  • Design
  • Anti-glare screen
  • Yes
  • Bezel width (bottom)
  • 4.57 cm
  • Bezel width (side)
  • 1.77 cm
  • Bezel width (top)
  • 1.77 cm
  • Orientation
  • Horizontal
  • Panel mounting interface
  • 800 x 600 mm
  • Placement supported
  • Indoor
  • Product colour
  • Black
  • Product design
  • Digital signage flat panel
  • Screen shape
  • Flat
  • VESA mounting
  • Yes
  • Display
  • Contrast ratio (typical)
  • 1200:1
  • Display brightness
  • 390 cd/m²
  • Display number of colours
  • 1.07 billion colours
  • HD type
  • 4K Ultra HD
  • LED backlighting type
  • Direct-LED
  • Multi-touch
  • Yes
  • Native aspect ratio
  • 16:9
  • Native refresh rate
  • 60 Hz
  • Number of simultaneous touchpoints
  • 20
  • Panel type
  • IPS
  • Rated lifetime
  • 30000 h
  • Response time
  • 8.5 ms
  • RGB colour space
  • NTSC
  • Screen Resolution
  • 3840 x 2160 pixels
  • Screen Size
  • 2.18 m (86")
  • Screen Type
  • LED
  • Surface hardness
  • 7H
  • Touchscreen
  • Yes
  • Touchscreen technology
  • Infrared
  • Viewing angle, horizontal
  • 178°
  • Viewing angle, vertical
  • 178°
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 80%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Other features
  • Bluetooth
  • Yes
  • Bluetooth version
  • 5.0
  • Packaging content
  • Batteries included
  • Yes
  • Cables included
  • USB Type-A to USB Type-B, AC, HDMI
  • Number of stylus pens
  • 2
  • Remote control included
  • Yes
  • Stylus pen
  • Yes
  • Packaging data
  • Package depth
  • 225 mm
  • Package height
  • 1283 mm
  • Package weight
  • 80.7 kg
  • Package width
  • 2110 mm
  • Performance
  • HDCP
  • Yes
  • HDCP version
  • 1.4/2.2
  • On Screen Display (OSD)
  • Yes
  • Open Pluggable Specification (OPS)
  • Yes
  • Operating hours (hours/days)
  • 16/7
  • Purpose
  • Education
  • Ports & interfaces
  • DisplayPorts quantity
  • 0
  • DVI port
  • No
  • Ethernet LAN
  • Yes
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • HDMI input ports quantity
  • 3
  • HDMI output ports quantity
  • 1
  • HDMI ports
  • 4
  • Infrared data port
  • Yes
  • OPS module slot
  • Yes
  • PC Audio in
  • Yes
  • PC Audio out
  • Yes
  • Remote (IR) input
  • 1
  • RS-232C
  • Yes
  • USB connector type
  • USB Type-A, USB Type-B, USB Type-C
  • USB port
  • Yes
  • USB version
  • 2.0/3.2 Gen 1 (3.1 Gen 1)
  • Wi-Fi
  • Yes
  • Wi-Fi standards
  • Wi-Fi 5 (802.11ac)
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 240 V
  • Power consumption (off)
  • 0.5 W
  • Power consumption (typical)
  • 320 W
  • Weight & dimensions
  • Display depth
  • 87 mm
  • Display height
  • 1160 mm
  • Display weight
  • 65.8 kg
  • Display width
  • 1957 mm
