Description

Mercusys AC1200 Wireless Dual Band Gigabit Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 1167 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: WPA-PSK, WPA2-PSK, Firewall security: SPI Firewall, IP/MAC Address Binding, NAT functionality: Port Forwarding, Port Triggering, UPnP, DMZ. Supported network protocols: PPPoE/L2TP/PPTP

AC1200 Gigabit WiFi – Enjoy home entertainment without any lag, reaching speeds up to 1.2 Gbps (867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band)
Broader Coverage – 4× high-gain antennas with Beamforming boost stable connections throughout your home for strong WiFi signals in every corner
Full Gigabit Ports – Make full use of your internet access and transfer data at dizzying speeds for peak performance
Higher Network Efficiency – MU-MIMO technology allows MR30G to communicate with multiple devices at the same time, increasing WiFi throughput for each device
Easily Manage Your Home Network – Varied software functions such as Parental Controls, QoS, and Guest Network for safety and effectiveness
IPTV Supported – Supports IGMP Proxy/Snooping, Bridge, and Tag VLAN to optimize IPTV streaming
IPv6 Supported – Allows you to both enjoy the IPv6 services provided by your ISP and visit IPv6 websites

Product Properties

Manufacturer
Mercusys

Model
MR30G

EAN
6957939000622

Antenna

Antenna design
External

Antenna gain level (max)
5 dBi

Antennas quantity
4

Bullet points

Point
IPTV Supported – Supports IGMP Proxy/Snooping, Bridge, and Tag VLAN to optimize IPTV streaming

Design

LED indicators
Status

Product colour
Black

Product type
Tabletop router

Management features

MIMO
Yes

MU-MIMO technology
Yes

Reset button
Yes

Web-based management
Yes

WPS push button
Yes

Mobile network

Network

Cabling technology
10/100/1000Base-T(X)

Ethernet LAN
Yes

Ethernet LAN data rates
10,100,1000 Mbit/s

Ethernet LAN interface type
Gigabit Ethernet

Receiver sensitivity
11g 6Mbps: -96dBm 11g 54Mbps: -78dBm 11n HT40 MCS7: -74dBm 11n HT20 MCS7: -71dBm 11a 6Mbps: -97dBm 11a 54Mbps: -79dBm 11ac VHT20 MCS8: -74dBm 11ac VHT40 MCS9: -70dBm 11ac VHT80 MCS9: -65dBm

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Packaging content

AC adapter included
Yes

Antenna included
Yes

Cables included
LAN (RJ-45)

Quick installation guide
Yes

Packaging data

Package type
Box

Ports & interfaces

DC-in jack
Yes

Ethernet LAN (RJ-45) ports
3

USB port
No

Power

External power adapter
Yes

Power source type
AC

Protocols

DHCP client
Yes

DHCP server
Yes

Supported network protocols
PPPoE/L2TP/PPTP

Security

Access Control List (ACL)
Yes

Firewall
Yes

Firewall security
SPI Firewall, IP/MAC Address Binding

Guest access
Yes

NAT functionality
Port Forwarding, Port Triggering, UPnP, DMZ

Network address translation (NAT)
Yes

Parental control
Yes

Security algorithms
WPA-PSK, WPA2-PSK

WAN connection

3G/4G USB modem compatibility
No

DSL WAN
No

Ethernet WAN
Yes

SIM card slot
No

WAN connection type
RJ-45

Weight & dimensions

Depth
125.9 mm

Height
37.1 mm

Width
159.7 mm

Wireless LAN features

Top Wi-Fi standard
Wi-Fi 5 (802.11ac)

Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)

Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

WLAN data transfer rate (first band)
300 Mbit/s

WLAN data transfer rate (max)
1167 Mbit/s

WLAN data transfer rate (second band)
867 Mbit/s
