NETGEAR GS316EPP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Roll over image to zoom inClick to Open expanded view
NETGEAR GS316EPP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
NETGEAR GS316EPP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
NETGEAR GS316EPP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
NETGEAR GS316EPP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Print
Model: GS316EPP-100UKS
EAN: 606449154412

NETGEAR GS316EPP Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Manufacturer:
Netgear
NETGEAR GS316EPP, Managed, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Wall mountable
Please log in to see your price
Related products

Description

NETGEAR GS316EPP. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 4096 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE.... Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable

Product Properties

  • Model
  • GS316EPP-100UKS
  • EAN
  • 606449154412
  • Certificates
  • Certification
  • FCC 15 B CE/EN55032/24 VCCI ACMA CSA KC BSMI
  • Compliance certificates
  • CE
  • Data transmission
  • Jumbo frames
  • 10000
  • Jumbo frames support
  • Yes
  • MAC address table
  • 4096 entries
  • Packet buffer memory
  • 0.192 MB
  • Store-and-forward
  • Yes
  • Switching capacity
  • 32 Gbit/s
  • Design
  • Housing material
  • Metal
  • LED indicators
  • Yes
  • Product colour
  • Black
  • Rack mounting
  • No
  • Wall mountable
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Switch type
  • Managed
  • Web-based management
  • Yes
  • Multicast features
  • Multicast support
  • Yes
  • Number of multicast groups filtered
  • 128
  • Network
  • 10G support
  • No
  • Copper ethernet cabling technology
  • 10BASE-T, 100BASE-TX, 1000BASE-T
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • Flow control support
  • Yes
  • Full duplex
  • Yes
  • Link aggregation
  • Yes
  • Networking standards
  • IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • Number of VLANs
  • 64
  • Port mirroring
  • Yes
  • Rate limiting
  • Yes
  • Virtual LAN features
  • Port-based VLAN, Tagged VLAN
  • VLAN support
  • Yes
  • Operational conditions
  • Non-operating altitude
  • 0 - 3000 m
  • Operating altitude
  • 0 - 3000 m
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Packaging content
  • Cables included
  • AC
  • User guide
  • Yes
  • Ports & interfaces
  • Installed SFP+ modules quantity
  • 0
  • Power connector
  • DC-in jack
  • SFP module slots quantity
  • 1
  • Switch Number of Ports
  • 16
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet plus (PoE+) ports quantity
  • 15
  • Total Power over Ethernet (PoE) budget
  • 231 W
  • Security
  • DHCP features
  • DHCP client
  • IGMP snooping
  • Yes
  • Password protection
  • Yes
  • Queue scheduling algorithms
  • Weighted Round Robin (WRR)
  • Sustainability
  • Sustainability compliance
  • Yes
  • Weight & dimensions
  • Depth
  • 102 mm
  • Height
  • 27 mm
  • Weight
  • 880 g
  • Width
  • 286 mm
