NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black
Roll over image to zoom inClick to Open expanded view
NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black
NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black
NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black
NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black
NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black
Print
Model: GS324-200EUS
EAN: 606449152012

NETGEAR GS324 Unmanaged Gigabit Ethernet (10/100/1000) Black

Manufacturer:
Netgear
NETGEAR GS324, Unmanaged, Gigabit Ethernet (10/100/1000), Rack mounting, Wall mountable
Please log in to see your price
Related products

Description

NETGEAR GS324. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE.... Wall mountable, Rack mounting
  • Choice of Fast Ethernet and Gigabit Ethernet connectivity
  • Energy-efficient technology for power savings
  • Auto-MDI/MDIX eliminates the need for crossover cables
  • Non-blocking switching architecture for maximum throughput at wire speed
  • Auto-negotiation for automatic connection at the highest common speed between switch and an end device
  • Desktop, wall or rackmountable

Product Properties

  • Model
  • GS324-200EUS
  • EAN
  • 606449152012
  • Bullet points
  • Point
  • Auto-MDI/MDIX eliminates the need for crossover cables
    Choice of Fast Ethernet and Gigabit Ethernet connectivity
    Desktop, wall or rackmountable
    Energy-efficient technology for power savings
    Non-blocking switching architecture for maximum throughput at wire speed
  • Certificates
  • Certification
  • CE Mark, FCC 15 A, IC A, RCM, CCC, VCCI, KC, CB, CE LVD
  • Data transmission
  • Jumbo frames
  • 9216
  • Jumbo frames support
  • Yes
  • Latency (1 Gbps)
  • 4.7 µs
  • MAC address table
  • 8000 entries
  • Packet buffer memory
  • 0.512 MB
  • Packet forwarding rate (1 Gbps)
  • 1448000 pps
  • Switching capacity
  • 48 Gbit/s
  • Design
  • Housing material
  • Metal
  • LED indicators
  • Activity, Link, Power, Speed
  • Product colour
  • Black
  • Rack mounting
  • Yes
  • Wall mountable
  • Yes
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Switch type
  • Unmanaged
  • Network
  • Auto MDI/MDI-X
  • Yes
  • Auto-sensing
  • Yes
  • Cable types supported
  • Cat5
  • Networking standards
  • IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • Operational conditions
  • Heat dissipation
  • 37.96 BTU/h
  • Operating altitude
  • 0 - 3000 m
  • Operating relative humidity (H-H)
  • 0 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 0 - 95%
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Packaging content
  • Cables included
  • AC
  • Manual
  • Yes
  • Performance
  • Fanless
  • Yes
  • Mean time between failures (MTBF)
  • 620798 h
  • Ports & interfaces
  • Switch Number of Ports
  • 24
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 110 - 240 V
  • Input current
  • 1 A
  • Power consumption (max)
  • 11.1 W
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • No
  • Weight & dimensions
  • Depth
  • 180 mm
  • Height
  • 44 mm
  • Weight
  • 1.31 kg
  • Width
  • 252 mm
