Model: GS748T-600EUS
EAN: 606449169218

NETGEAR GS748Tv6 Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Black, Grey

Manufacturer:
Netgear
NETGEAR GS748Tv6, Managed, L2/L3/L4, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

NETGEAR GS748Tv6. Switch type: Managed, Switch layer: L2/L3/L4. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000 entries, Switching capacity: 100 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE.... Rack mounting

Product Properties

  • Model
  • GS748T-600EUS
  • EAN
  • 606449169218
  • Certificates
  • Certification
  • CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
  • Data transmission
  • Jumbo frames support
  • Yes
  • MAC address table
  • 16000 entries
  • Number of queues
  • 8
  • Number of static routes
  • 32
  • Store-and-forward
  • Yes
  • Switching capacity
  • 100 Gbit/s
  • Design
  • LED indicators
  • Activity, Link, Power
  • Product colour
  • Black, Grey
  • Rack mounting
  • Yes
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Switch layer
  • L2/L3/L4
  • Switch type
  • Managed
  • System event log
  • Yes
  • Web-based management
  • Yes
  • Multicast features
  • Multicast support
  • Yes
  • Number of multicast groups filtered
  • 512
  • Network
  • Broadcast storm control
  • Yes
  • Copper ethernet cabling technology
  • 10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
  • Flow control support
  • Yes
  • Full duplex
  • Yes
  • IP routing
  • Yes
  • Networking standards
  • IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • Number of VLANs
  • 256
  • Port mirroring
  • Yes
  • Spanning tree protocol
  • Yes
  • VLAN support
  • Yes
  • Operational conditions
  • Non-operating altitude
  • 0 - 3000 m
  • Operating altitude
  • 0 - 3000 m
  • Operating relative humidity (H-H)
  • 0 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 0 - 95%
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Packaging content
  • Cables included
  • AC
  • Manual
  • Yes
  • Performance
  • Firmware upgradeable
  • Yes
  • Mean time between failures (MTBF)
  • 390728 h
  • Noise level
  • 37.2 dB
  • Ports & interfaces
  • Combo SFP ports quantity
  • 2
  • SFP module slots quantity
  • 2
  • Switch Number of Ports
  • 48
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • AC input voltage
  • 100 - 240 V
  • Power consumption (typical)
  • 41.1 W
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • No
  • Protocols
  • Management protocols
  • SNMP v1/v2
  • Supported network protocols
  • IP
  • Security
  • Access Control List (ACL)
  • Yes
  • DHCP features
  • DHCP client
  • IGMP snooping
  • Yes
  • MAC address filtering
  • Yes
  • Security algorithms
  • 802.1x RADIUS, HTTPS, SSL/TLS
  • SSH/SSL support
  • Yes
  • Weight & dimensions
  • Depth
  • 257 mm
  • Height
  • 43 mm
  • Weight
  • 3.46 kg
  • Width
  • 440 mm
