Description

StarTech.com Dual-Monitor USB4 Docking Station, Dual 4K 120Hz or Single 8K 60Hz HDMI, 100W Laptop Charging, 2.5GbE, USB-C Multi-Monitor Dock, Driverless. Connectivity technology: Wired, Host interface: USB4, USB Power Delivery up to: 100 W. Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Product colour: Silver, Data transfer rate: 40 Gbit/s, HD type: 4K Ultra HD. Power source type: DC, AC input voltage: 100 - 240 V, Input current: 2.5 A. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Other operating systems supported: ChromeOS

Dual 4K@120Hz over USB4: Connect two 4K 120Hz or 60Hz displays through a single USB4 or Thunderbolt 4 port with uncompressed video powered by your laptop's native GPU; Drive demanding workflows with high-performance visuals and no software compression
Driverless Deployment: Plug-and-play on Windows and ChromeOS with no drivers or software to install (not compatible with macOS); Engineered for scalable zero-touch rollouts across shared workspaces, corporate, and BYOD environments
2.5G Ethernet for High-Speed Networking: Transfer large files or work directly from cloud environments with a reliable 2.5GbE connection; Supports PXE Boot and Wake-on-LAN for IT-managed deployments
Mounting and Security: Multi-monitor dock features built-in lock slots for physical security; Supports surface or VESA mounting to keep the dock secured and out of the way (mounting accessories sold separately: SSPMSUDWM, DOCK-NUC-VESA-MOUNT, SSPMSVESA)
The IT Pro's Choice: Our docking stations are rigorously tested in our Innovation Lab to ensure enterprise-grade reliability and cross-platform compatibility; Built to support large-scale deployments, Windows 11 upgrades, and the shift to AI-enabled PCs

Product Properties

Manufacturer
StarTech.com

Model
155UE-USB4-DOCK

EAN
65030902878

Bullet points

Point
2.5G Ethernet for High-Speed Networking

Driverless Deployment

Dual 4K@120Hz over USB4

Mounting and Security

The IT Pro's Choice

Logistics data

Master (outer) case height
265 mm

Master (outer) case length
375 mm

Master (outer) case width
305 mm

Products per master (outer) case
8 pc(s)

Network

Ethernet LAN
Yes

Ethernet LAN (RJ-45) ports
1

Ethernet LAN data rates
10,100,1000,2500 Mbit/s

Full duplex
Yes

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
0 - 95%

Operating temperature (T-T)
0 - 40 °C

Storage temperature (T-T)
-20 - 70 °C

Other features

Chipset
VIA - VL830, VIA - VL163, Realtek - RTD2188-VA-CG, Genesys Logic - GL9901NE

Packaging content

Cables included
USB

Quick start guide
Yes

Packaging data

Package depth
230 mm

Package height
89 mm

Package weight
1.3 kg

Package width
145 mm

Performance

Cable lock slot
Yes

Cable lock slot type
Kensington, Nano

Card reader integrated
No

Data transfer rate
40 Gbit/s

HD type
4K Ultra HD

Housing material
Plastic

LED indicators
Yes

Maximum digital resolution
3840 x 2160 pixels

Maximum refresh rate
120 Hz

Number of displays supported
2

On/off switch
Yes

Product colour
Silver

UASP support
Yes

Ports & interfaces

Connectivity technology
Wired

DC-in jack
Yes

HDMI ports
2

Headphone outputs
0

Host interface
USB4

Microphone in
No

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1

USB Power Delivery (USB PD)
Yes

USB Power Delivery up to
100 W

Power

AC input voltage
100 - 240 V

Compatible power plug types
EU, UK

Input current
2.5 A

Output current
9 A

Output voltage
20 V

Power consumption (typical)
165 W

Power plug type
Type M

Power source type
DC

Software

Other operating systems supported
ChromeOS

Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64

Weight & dimensions

Depth
95 mm

Height
34 mm

Weight
138.6 g

Width
210 mm
