StarTech.com HP JD089B Compatible SFP Transceiver Module - 10/100/1000BASE-TX~HPE JD089B Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m - HPE 5820AF, 12500, 5500
Roll over image to zoom inClick to Open expanded view
Model: JD089BST
EAN: 65030868556

StarTech.com HP JD089B Compatible SFP Transceiver Module - 10/100/1000BASE-TX~HPE JD089B Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m - HPE 5820AF, 12500, 5500

Manufacturer:
StarTech.com
StarTech.com HP JD089B Compatible SFP Transceiver Module - 10/100/1000BASE-TX~HPE JD089B Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m - HPE 5820AF, 12500, 5500, Copper, 1000 Mbit/s, SFP, 100 m, IEEE 8
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

StarTech.com HP JD089B Compatible SFP Transceiver Module - 10/100/1000BASE-TX~HPE JD089B Compatible SFP Module - 1000BASE-T - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m - HPE 5820AF, 12500, 5500. SFP transceiver type: Copper, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Product colour: Silver, Housing material: Aluminium, Mean time between failures (MTBF): 4655371 h. Power consumption (typical): 1.3 W. Width: 13.7 mm, Depth: 68 mm, Height: 13.8 mm. Number of products included: 1 pc(s), Package width: 119 mm, Package depth: 93 mm
  • 100% HPE JD089B COMPATIBLE: Works with HPE switches like 5820AF, 12500, 5500, E4800, E4500 and others
  • TECHNICAL SPECS: 1000BASE-T / 1Gbps / Copper / RJ-45 Connector / Distances up to 100m (328ft)
  • TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in HPE routers and switches
  • WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
  • THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance

Product Properties

  • Model
  • JD089BST
  • EAN
  • 65030868556
  • Bullet points
  • Point
  • 100% HPE JD089B COMPATIBLE
    TECHNICAL SPECS: 1000BASE-T / 1Gbps / Copper / RJ-45 Connector / Distances up to 100m (328ft)
    TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in HPE routers and switches
    THE IT PRO’S CHOICE
    WORKS WITH MSA COMPLIANT SWITCHES
  • Features
  • Certification
  • CE, FCC, UR
  • Hot-swap
  • Yes
  • Housing material
  • Aluminium
  • Mean time between failures (MTBF)
  • 4655371 h
  • Product colour
  • Silver
  • Logistics data
  • Harmonized System (HS) code
  • 85369010
  • Master (outer) case height
  • 355 mm
  • Master (outer) case length
  • 410 mm
  • Master (outer) case width
  • 350 mm
  • Products per master (outer) case
  • 100 pc(s)
  • Operational conditions
  • Operating relative humidity (H-H)
  • 5 - 95%
  • Operating temperature (T-T)
  • 0 - 70 °C
  • Storage temperature (T-T)
  • -40 - 85 °C
  • Packaging data
  • Number of products included
  • 1 pc(s)
  • Package depth
  • 93 mm
  • Package height
  • 35 mm
  • Package weight
  • 54 g
  • Package width
  • 119 mm
  • Performance
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Digital Diagnostics Monitoring (DDM)
  • No
  • Duplex system
  • Full
  • Ethernet LAN (RJ-45) ports
  • 1
  • Interface type
  • SFP
  • Maximum data transfer rate
  • 1000 Mbit/s
  • Maximum transfer distance
  • 100 m
  • Networking standards
  • IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
  • SFP transceiver type
  • Copper
  • Power
  • Power consumption (typical)
  • 1.3 W
  • Technical details
  • Sustainability certificates
  • RoHS
  • Weight & dimensions
  • Depth
  • 68 mm
  • Height
  • 13.8 mm
  • Weight
  • 25 g
  • Width
  • 13.7 mm
