StarTech.com MSA Uncoded Compatible 3m 10G SFP+ to SFP+ Direct Attach Breakout Cable Twinax - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Transceiver Module DAC
Roll over image to zoom inClick to Open expanded view
StarTech.com MSA Uncoded Compatible 3m 10G SFP+ to SFP+ Direct Attach Breakout Cable Twinax - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Transceiver Module DAC
StarTech.com MSA Uncoded Compatible 3m 10G SFP+ to SFP+ Direct Attach Breakout Cable Twinax - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Transceiver Module DAC
Print
Model: SFP10GPC3M
EAN: 65030874885

StarTech.com MSA Uncoded Compatible 3m 10G SFP+ to SFP+ Direct Attach Breakout Cable Twinax - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Transceiver Module DAC

Manufacturer:
StarTech.com
StarTech.com MSA Uncoded Compatible 3m 10G SFP+ to SFP+ Direct Attach Breakout Cable Twinax - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Transceiver Module DAC, 3 m, SFP+, SFP+
Please log in to see your price
Related products

Description

StarTech.com MSA Uncoded Compatible 3m 10G SFP+ to SFP+ Direct Attach Breakout Cable Twinax - 10 GbE SFP+ Copper DAC 10 Gbps Low Power Passive Transceiver Module DAC. Cable length: 3 m, Connector 1: SFP+, Connector 2: SFP+
  • MSA UNCODED SFP+ CABLE (DAC): 10G direct attach cable works with MSA compliant switches the accept uncoded transceivers and modules
  • TECHNICAL SPECS: 3m (9.84ft) / 10 Gbps / Passive Twinax (Copper) / 2x SFP+ Pluggable Connector / 100 Ohm Impedance / 30 AWG Wire Gauge / PVC Cable Jacket / Hot swappable / MSA Compliant
  • DESIGNED FOR SERVER ROOMS: Mini GBIC DAC is a cost-effective copper alternative to fiber cable inside & between racks. Factory termination means high performance & reliability with less maintenance.
  • OUTSTANDING SUPPORT: Backed by StarTech.com for the life of the cable itself, not your equipment; our cables won't void your OEM support and with access to our Tech Advisors 5/24
  • WORKS WITH MSA COMPLIANT SWITCHES: Low power 10 GbE DAC also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules and transceivers

Product Properties

  • Model
  • SFP10GPC3M
  • EAN
  • 65030874885
  • Bullet points
  • Point
  • DESIGNED FOR SERVER ROOMS
    MSA UNCODED SFP+ CABLE (DAC)
    OUTSTANDING SUPPORT
    TECHNICAL SPECS
    WORKS WITH MSA COMPLIANT SWITCHES
  • Certificates
  • Certification
  • CE, FCC
  • Compliance certificates
  • RoHS
  • Features
  • Cable length
  • 3 m
  • Connector 1
  • SFP+
  • Connector 1 gender
  • Male
  • Connector 2
  • SFP+
  • Connector 2 gender
  • Male
  • Data transfer rate
  • 10000 Mbit/s
  • InfiniBand protocol
  • Yes
  • Jacket material
  • Polyvinyl chloride (PVC)
  • Plug and Play
  • Yes
  • Product colour
  • Black
  • Logistics data
  • Harmonized System (HS) code
  • 84733080
  • Master (outer) case height
  • 295 mm
  • Master (outer) case length
  • 344 mm
  • Master (outer) case width
  • 255 mm
  • Products per master (outer) case
  • 10 pc(s)
  • Operational conditions
  • Operating temperature (T-T)
  • 0 - 70 °C
  • Storage temperature (T-T)
  • -40 - 80 °C
  • Packaging content
  • Quantity per pack
  • 1 pc(s)
  • Packaging data
  • Package depth
  • 200 mm
  • Package height
  • 4 mm
  • Package weight
  • 150 g
  • Package width
  • 218 mm
  • Weight & dimensions
  • Weight
  • 150 g
