StarTech.com Thunderbolt 3 Mini Dock - Portable Dual Monitor Docking Station w/HDMI 4K 60Hz, 2x USB-A Hub (3.0/2.0), GbE - 11in/28cm Cable - TB3 Multiport Adapter - Mac/Windows
Roll over image to zoom inClick to Open expanded view
Model: TB3DKM2HDL
EAN: 65030888042

StarTech.com Thunderbolt 3 Mini Dock - Portable Dual Monitor Docking Station w/HDMI 4K 60Hz, 2x USB-A Hub (3.0/2.0), GbE - 11in/28cm Cable - TB3 Multiport Adapter - Mac/Windows

Manufacturer:
StarTech.com
StarTech.com Thunderbolt 3 Mini Dock - Portable Dual Monitor Docking Station w/HDMI 4K 60Hz, 2x USB-A Hub (3.0/2.0), GbE - 11in/28cm Cable - TB3 Multiport Adapter - Mac/Windows, Wired, Thunderbolt 3, 10,100,1000 Mbit/s, IEEE 802.3ab, IEEE 802.3i, IEEE 802
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

StarTech.com Thunderbolt 3 Mini Dock - Portable Dual Monitor Docking Station w/HDMI 4K 60Hz, 2x USB-A Hub (3.0/2.0), GbE - 11in/28cm Cable - TB3 Multiport Adapter - Mac/Windows. Connectivity technology: Wired, Host interface: Thunderbolt 3. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u. Product colour: Grey, Maximum digital resolution: 3840 x 2160 pixels. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High..., Server operating systems supported: Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 x64. Width: 69 mm, Depth: 124 mm, Height: 27 mm
  • HIGH PERFORMANCE THUNDERBOLT 3 CERTIFIED DOCK: Driverless setup for plug-and-play installation; Thunderbolt 3 (40 Gbps); Dual 4K 60Hz HDMI outputs; 2-Port USB-A Hub (1x USB 3.2 Gen 1 5Gbps & 1x USB 2.0); Gigabit Ethernet port with PXE boot and WoL
  • FOR HIGH-POWERED LAPTOPS: Dual 4K 60Hz video output with direct GPU performance and no software or compression; Ideal for high-performance laptops that need a direct power adapter connection, but require Thunderbolt 3 dock performance & functionality
  • COMPATIBILITY: This docking station is compatible with Windows, macOS, and Ubuntu; Supports Thunderbolt or USB4 laptops; Dual Display on M1, M2, M3 Max/Pro, M4 Pro/Max MacBooks, and single display on base M-series MacBooks and iPad Pro M1 & later
  • EXTRA-LONG CABLE: Attached 11in (28cm) cable provides long reach for easy setup and prevents adapter from dangling on the host connector; Ideal cable length to reduce port strain on 2-in-1 convertible laptops, or host laptops on riser stands
  • OUR ADVANTAGE: Included connectivity tools for IT Pros and IT help-desk support teams with Network MAC Address Pass-Through for network security, WiFi Auto Switching for improved network performance, USB Event Monitoring, and Windows Layout

Product Properties

  • Model
  • TB3DKM2HDL
  • EAN
  • 65030888042
  • Bullet points
  • Point
  • COMPATIBILITY
    EXTRA-LONG CABLE
    FOR HIGH-POWERED LAPTOPS
    HIGH PERFORMANCE THUNDERBOLT 3 CERTIFIED DOCK
    OUR ADVANTAGE
  • Logistics data
  • Harmonized System (HS) code
  • 84733020
  • Master (outer) case height
  • 270 mm
  • Master (outer) case length
  • 437 mm
  • Master (outer) case width
  • 300 mm
  • Products per master (outer) case
  • 24 pc(s)
  • Network
  • Ethernet LAN
  • Yes
  • Ethernet LAN (RJ-45) ports
  • 1
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • Networking standards
  • IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
  • Wake-on-LAN ready
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 0 - 95%
  • Operating temperature (T-T)
  • 5 - 40 °C
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Other features
  • Cable length
  • 0.28 m
  • Chipset
  • Intel JHL6540 (Alpine Ridge), Texas Instruments TPS65983A, Parade PS176, ASMedia ASM1042A, Intel WGI210
  • Packaging content
  • Manual
  • Yes
  • Packaging data
  • Package depth
  • 195 mm
  • Package height
  • 37 mm
  • Package weight
  • 270 g
  • Package width
  • 139 mm
  • Performance
  • Card reader integrated
  • No
  • Maximum digital resolution
  • 3840 x 2160 pixels
  • Number of displays supported
  • 2
  • Product colour
  • Grey
  • Ports & interfaces
  • Connectivity technology
  • Wired
  • HDMI ports
  • 2
  • Headphone outputs
  • 0
  • Host interface
  • Thunderbolt 3
  • Microphone in
  • No
  • USB 2.0 ports quantity
  • 1
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
  • 1
  • Software
  • Mac operating systems supported
  • Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura
  • Server operating systems supported
  • Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 x64
  • Windows operating systems supported
  • Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
  • Technical details
  • Compliance certificates
  • RoHS
  • Weight & dimensions
  • Depth
  • 124 mm
  • Height
  • 27 mm
  • Weight
  • 147.8 g
  • Width
  • 69 mm
