Description

StarTech.com Thunderbolt 3 Mini Dock - Portable Dual Monitor Docking Station with DP 4K 60Hz, 1x USB-A Hub (USB 3.0/5 Gbps), GbE - 11in/28cm Cable - TB3 Multiport Adapter - Mac/Windows. Connectivity technology: Wired, Host interface: Thunderbolt 3. Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u. Product colour: Grey, Data transfer rate: 5 Gbit/s, Maximum digital resolution: 3840 x 2160 pixels. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High..., Server operating systems supported: Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 x64. Width: 69 mm, Depth: 124 mm, Height: 27 mm

HIGH-PERFORMANCE THUNDERBOLT 3 CERTIFIED DOCK: Driverless setup for plug-and-play installation; Thunderbolt 3 (40 Gbps); Dual 4K 60Hz DisplayPort (DP) outputs; 1x USB 3.2 Gen 1 Type-A (5Gbps) port; Gigabit Ethernet port with PXE boot and WoL
FOR HIGH-POWERED LAPTOPS: Dual 4K 60Hz video output with direct GPU performance and no software or compression; Ideal for high-performance laptops that need a direct power adapter connection, but require Thunderbolt 3 dock performance & functionality
COMPATIBILITY: This docking station is compatible with Windows, macOS, and Ubuntu; Supports Thunderbolt or USB4 laptops; Dual Display on M1, M2, M3 Max/Pro, M4 Pro/Max MacBooks, and single display on base M-series MacBooks and iPad Pro M1 & later
EXTRA-LONG CABLE: Attached 11in (28cm) cable provides long reach for easy setup and prevents adapter from dangling on the host connector; Ideal cable length to reduce port strain on 2-in-1 convertible laptops, or host laptops on riser stands
OUR ADVANTAGE: Included connectivity tools for IT Pros and IT help-desk support teams with Network MAC Address Pass-Through for network security, WiFi Auto Switching for improved network performance, USB Event Monitoring, and Windows Layout

Product Properties

Manufacturer
StarTech.com

Model
TB3DKM2DPL

EAN
65030888059

Bullet points

Point
COMPATIBILITY

EXTRA-LONG CABLE

FOR HIGH-POWERED LAPTOPS

HIGH-PERFORMANCE THUNDERBOLT 3 CERTIFIED DOCK

OUR ADVANTAGE

Logistics data

Harmonized System (HS) code
84733020

Master (outer) case height
270 mm

Master (outer) case length
437 mm

Master (outer) case width
300 mm

Products per master (outer) case
24 pc(s)

Network

Ethernet LAN
Yes

Ethernet LAN (RJ-45) ports
1

Ethernet LAN data rates
10,100,1000 Mbit/s

Networking standards
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
0 - 95%

Operating temperature (T-T)
5 - 40 °C

Storage temperature (T-T)
-20 - 70 °C

Other features

Cable length
0.28 m

Chipset
Intel JHL6540 (Alpine Ridge), Texas Instruments TPS65983A, Parade PS176, ASMedia ASM1042A, Intel WGI210

Packaging content

Manual
Yes

Packaging data

Package depth
195 mm

Package height
37 mm

Package weight
270 g

Package width
139 mm

Performance

Card reader integrated
No

Data transfer rate
5 Gbit/s

Housing material
Aluminium, Plastic

Maximum digital resolution
3840 x 2160 pixels

Number of displays supported
2

Product colour
Grey

Ports & interfaces

Connectivity technology
Wired

DisplayPorts quantity
2

HDMI ports
0

Headphone outputs
0

Host interface
Thunderbolt 3

Microphone in
No

USB 2.0 ports quantity
0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1

Software

Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura

Server operating systems supported
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 x64

Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64

Technical details

Compliance certificates
CE, RoHS

Weight & dimensions

Depth
124 mm

Height
27 mm

Weight
147.8 g

Width
69 mm
