Description

StarTech.com USB C to DisplayPort Adapter - 8K/5K/4K USB Type C to DP 1.4 Alt Mode Video Converter - HBR3/DSC/HDR - 8K 60Hz Thunderbolt 3 Compatible DisplayPort Monitor Display Adapter. USB connector type: USB Type-C, USB connector gender: Male, Maximum resolution: 7680 x 4320 pixels. Product colour: Black. Width: 60 mm, Depth: 24 mm, Height: 15 mm. Package width: 200 mm, Package depth: 220 mm, Package weight: 44 g. Products per master (outer) case: 120 pc(s), Master (outer) case width: 500 mm, Master (outer) case length: 330 mm

HIGH PERFORMANCE: USB-C to DisplayPort 1.4 (32.4Gbps) adapter compatible w/ HDR/DisplayHDR, HBR3, Display Stream Compression (DSC), HDCP 2.2/1.4; 8K 60Hz (7680x4320), 5K 60Hz, 4K 120Hz & 1080p
EXPERIENCE 8K: USB C to DisplayPort adapter was tested with 8K monitors, displays & compliance test hardware/software for optimal performance & color depth for high res imaging & content creators
TESTED & VERIFIED: With USB-C DP Alt Mode & Thunderbolt 3 devices like Lenovo ThinkPad X1 Carbon/Extreme, Dell XPS, HP EliteBook/ZBook, TB3 MacBook Pro 13 & 16/Air, iPad Pro, iPhone 15 (Plus/Pro/Max) and up, Surface Laptop 3/Pro 7
HIGH BUILD QUALITY: Robust & reliable USB Type C to DP adapter dongle w/ Level 4 Air/Contact ESD immunity/protection and EMI shielding for consistent, uninterrupted performance / FCC certified
COMPATIBILITY: This USB-C to DisplayPort video converter requires no software/drivers & is backwards compatible with DisplayPort 1.2; Works w/ Windows, MacOS, Linux, iPadOS, iOS, Chrome OS, Android

Product Properties

Manufacturer
StarTech.com

Model
CDP2DP14B

EAN
65030883634

Bullet points

Point
COMPATIBILITY

EXPERIENCE 8K

HIGH BUILD QUALITY

HIGH PERFORMANCE

TESTED & VERIFIED

Design

Product colour
Black

Logistics data

Harmonized System (HS) code
84733020

Master (outer) case height
220 mm

Master (outer) case length
330 mm

Master (outer) case width
500 mm

Products per master (outer) case
120 pc(s)

Operational conditions

Operating relative humidity (H-H)
30 - 60%

Operating temperature (T-T)
5 - 35 °C

Packaging data

Package depth
220 mm

Package weight
44 g

Package width
200 mm

Performance

Audio output channels
7.1 channels

Certification
CE, FCC, REACH

Chipset
STM32F072

DisplayPort output
Yes

DisplayPort version
1.4

DVI output
No

HDMI output
No

Maximum resolution
7680 x 4320 pixels

Number of displays supported
1

Refresh rate at maximum resolution
30 Hz

Supported graphics resolutions
1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160, 4096 x 2160, 7680 x 4320

USB connector gender
Male

USB connector type
USB Type-C

Technical details

Compliance certificates
RoHS

Weight & dimensions

Depth
24 mm

Height
15 mm

Weight
34 g

Width
60 mm
