Description

StarTech.com USB-C to Dual Displayport 1.4 Adapter, USB Type-C Multi-Monitor MST Hub, Dual 5K 60Hz DP Laptop Display Extender / Splitter, HDR, Extra-Long Built-In Cable - Windows Only. USB connector type: USB Type-C, USB connector gender: Male, USB connector form factor: Straight. Product colour: Grey, Housing material: Plastic. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10.... USB cable length: 0.3 m. Package width: 142 mm, Package depth: 170 mm, Package height: 30 mm

MULTI-MONITOR CONFIGURATION: USB Type-C to Dual DisplayPort MST Hub/Splitter drives up to two 5K 60Hz displays from a USB-C DP 1.4 host with DSC; USB Powered; Supports HDR and 2ch HDMI Audio; HDCP 2.2; TB3/TB4/USB4 Compatible; Not compatible with macOS
NO DRIVERS OR SOFTWARE: Increase productivity by adding two extended or mirrored displays to a Windows laptop; Utilize integrated or discrete GPU (Intel/AMD/Nvidia) capabilities enabling high performance graphics with minimal CPU usage
HARDWARE COMPATIBILITY: Dual 5K 60Hz supported on Windows PC with discrete GPUs or 12th gen and up Intel Processors featuring DP 1.4 with DSC; See resolution chart below for other configurations; Please verify number of displays supported by your GPU
EXTRA LONG CABLE: 1ft (30 cm) built-in cable for extended reach reduces port/connector strain on 2-in-1 devices like Surface Pro 7 and up, HP Elite x2/laptops on riser stands; Ideal for on-the-go travel use in office/home office/shared workspaces
OUR ADVANTAGE: Included connectivity tools for IT Pro's and IT help-desk support teams with Windows Layout Utility which restores windows app locations when re-connecting the USBC to Dual DisplayPort Adapter

Product Properties

Manufacturer
StarTech.com

Model
MST14CD122DP

EAN
65030884372

Bullet points

Point
EXTRA LONG CABLE

HARDWARE COMPATIBILITY

MULTI-MONITOR CONFIGURATION

NO DRIVERS OR SOFTWARE

OUR ADVANTAGE

Design

Housing material
Plastic

Product colour
Grey

Logistics data

Master (outer) case height
440 mm

Master (outer) case length
331 mm

Master (outer) case width
473 mm

Products per master (outer) case
70 pc(s)

Operational conditions

Operating relative humidity (H-H)
5 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage temperature (T-T)
-40 - 70 °C

Packaging data

Package depth
170 mm

Package height
30 mm

Package weight
108.8 g

Package width
142 mm

Performance

Audio output channels
2.0 channels

Chipset
Synaptics - VMM5220, VIA/VLI - VL103

DisplayPort output
Yes

DisplayPort version
1.4

DisplayPorts quantity
2

DVI output
No

HDCP
Yes

HDCP version
2.2

HDMI output
No

High Dynamic Range (HDR) supported
Yes

Maximum resolution
4096 x 2160 pixels

Number of displays supported
2

Refresh rate at maximum resolution
60 Hz

USB connector form factor
Straight

USB connector gender
Male

USB connector type
USB Type-C

System requirements

Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64

Technical details

Compliance certificates
CE, RoHS

Sustainability compliance
Yes

Weight & dimensions

USB cable length
0.3 m
