Description

TP-Link 5G AX3000 Wi-Fi 6 Telephony Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 3000 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Mobile network generation: 5G, 3G standards: DC-HSDPA, HSDPA, HSPA+, HSUPA, WCDMA, 4G standard: LTE-TDD & LTE-FDD. Product type: Tabletop router, Product colour: White, LED indicators: LAN, LTE, Status

Boost Your 5G Speed: Take advantage of your advanced 5G network with download speeds up to 3.4 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences
AX3000 Dual-Band Wi-Fi 6 Speed: 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
VoLTE/CSFB Telephony: With 1 Voice port, users can make or receive phone calls over the internet simply by connecting the device to their existing telephone set
Plug & Play: Enjoy 5G network right after inserting a SIM card
Support EasyMesh: Co-work with EasyMesh products, to provide a more flexible and cost-effective Mesh network with a single Wi-Fi name for seamless whole-home coverage
Fully Gigabit Ports for Consummate Connectivity: Fully gigabit Ethernet ports provide warp speeds and reliable connections for high-intensive wired devices such as your smart TV, game console, NAS, and more
Easy Remote Management: TR-069 and TR-369 protocols and TAUC (TP-Link Aginet Unified Cloud) are supported

Product Properties

Manufacturer
TP-LINK

Model
NX510V

EAN
4897098686874

Antenna

Antenna design
Internal & external

Bullet points

Point
AX3000 Dual-Band Wi-Fi 6 Speed: 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz)

Boost Your 5G Speed

Easy Remote Management

Fully Gigabit Ports for Consummate Connectivity

Plug & Play: Enjoy 5G network right after inserting a SIM card

Support EasyMesh

VoLTE/CSFB Telephony

Certificates

Certification
CE, RoHS

Design

LED indicators
LAN, LTE, Status

Product colour
White

Product type
Tabletop router

Features

Built-in processor
Yes

Processor cores
2

Processor frequency
1000 MHz

Management features

Quality of Service (QoS) support
Yes

Mobile network

3G standards
DC-HSDPA, HSDPA, HSPA+, HSUPA, WCDMA

4G standard
LTE-TDD & LTE-FDD

Mobile network generation
5G

Network

Cabling technology
10/100/1000Base-T(X)

Dynamic DNS (DDNS)
Yes

Ethernet LAN
Yes

Ethernet LAN data rates
10,100,1000 Mbit/s

Ethernet LAN interface type
Gigabit Ethernet

Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v

Port forwarding
Yes

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging content

AC adapter included
Yes

Cables included
LAN (RJ-45)

Quick start guide
Yes

Ports & interfaces

DC-in jack
Yes

Ethernet LAN (RJ-45) ports
3

USB port
No

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Output current
2 A

Output voltage
12 V

Power source type
AC

Security

Parental control
Yes

WAN connection

3G/4G USB modem compatibility
Yes

DSL WAN
Yes

Ethernet WAN
Yes

SIM card slot
Yes

WAN connection type
RJ-45

Weight & dimensions

Depth
99 mm

Height
192 mm

Width
99 mm

Wireless LAN features

Top Wi-Fi standard
Wi-Fi 6 (802.11ax)

Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)

Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

WLAN data transfer rate (first band)
574 Mbit/s

WLAN data transfer rate (max)
3000 Mbit/s

WLAN data transfer rate (second band)
2402 Mbit/s
