Description

TP-Link Archer AXE5400 Tri-Band Gigabit Wi-Fi 6E Router. WAN connection type: RJ-45. Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz), Top Wi-Fi standard: Wi-Fi 6E (802.11ax), WLAN data transfer rate (max): 5400 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 2500 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: WPA, WPA-Enterprise, WPA2, WPA3, Firewall security: SPI Firewall. Supported network protocols: IPv4, IPv6

AXE5400 Tri-Band – AXE5400 Tri-Band Wi-Fi delivers Wi-Fi speeds up to 5400 Mbps
Cutting-Edge Processing – Armed with a 1.7 GHz Quad-Core CPU
SuperSpeed USB 3.0 – Up to 10× faster transfer speeds than USB 2.0
Wi-Fi 6E Unleashed – The brand new 6 GHz band brings more bandwidth, faster speeds, and near-zero latency
HomeShield – Customize your home network with enhanced security and control
OneMesh™ – Creates a Mesh network by connecting to a TP-Link OneMesh Extender for seamless whole-home coverage
Connect More Devices—OFDMA technology increases capacity by 4 times to enable simultaneous transmission to more devices
Ultra-Low Latency—Enables more responsive gaming and video chatting
Compatible with Alexa—Control your router via voice commands and make your life smarter and easier with Amazon Alexa

Product Properties

Manufacturer
TP-LINK

Model
ARCHER AXE75

EAN
4897098687222

Antenna

Antenna design
External

Antennas quantity
6

Detachable antenna(s)
Yes

Transmit power
FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz)

Bullet points

Point
AXE5400 Tri-Band – AXE5400 Tri-Band Wi-Fi delivers Wi-Fi speeds up to 5400 Mbps

Cutting-Edge Processing – Armed with a 1.7 GHz Quad-Core CPU

HomeShield – Customize your home network with enhanced security and control

SuperSpeed USB 3.0 – Up to 10× faster transfer speeds than USB 2.0

Ultra-Low Latency—Enables more responsive gaming and video chatting

Certificates

Compliance certificates
Federal Communications Commission (FCC), RoHS

Design

LED indicators
Power, WAN, WLAN

On/off switch
Yes

Product colour
Black

Product type
Tabletop router

Wall mountable
Yes

Features

Built-in processor
Yes

Firmware upgradeable
Yes

Processor cores
4

Processor frequency
1700 MHz

Logistics data

Harmonized System (HS) code
85176990

Management features

Quality of Service (QoS) support
Yes

Reset button
Yes

Wake-on-LAN ready
Yes

Web-based management
Yes

Wireless statistics
Yes

WPS push button
Yes

Network

Built-in FTP server
Yes

Cabling technology
10/100/1000Base-T(X)

Dynamic DNS (DDNS)
Yes

Ethernet LAN
Yes

Ethernet LAN data rates
2500 Mbit/s

Ethernet LAN interface type
Gigabit Ethernet

Media server
Yes

Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n

Number of guest networks (2.4 GHz)
1

Number of guest networks (5 GHz)
1

Port forwarding
Yes

Port triggering
Yes

Static route
No

Support Samba (storage)
Yes

VPN Passthrough
Yes

VPN server
OpenVPN Server

VPN support
OpenVPN Server PPTP VPN Server L2TP VPN Server

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Packaging content

AC adapter included
Yes

Cables included
LAN (RJ-45)

Quick installation guide
Yes

Packaging data

Number of products included
1 pc(s)

Package depth
265 mm

Package height
120 mm

Package weight
1.53 kg

Package width
328 mm

Ports & interfaces

Ethernet LAN (RJ-45) ports
5

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1

USB port
Yes

Power

Output current
2.5 A

Output voltage
12 V

Power source type
DC

Protocols

DHCP client
Yes

DHCP server
Yes

Supported network protocols
IPv4, IPv6

Universal Plug and Play (UPnP)
Yes

Security

Access Control List (ACL)
Yes

DDoS protection
Yes

DMZ support
Yes

DoS attack prevention
Yes

Firewall
Yes

Firewall security
SPI Firewall

Guest access
Yes

IP address filtering
Yes

MAC address filtering
Yes

Network address translation (NAT)
Yes

Security algorithms
WPA, WPA-Enterprise, WPA2, WPA3

URL filtering
Yes

Sustainability

Sustainability compliance
Yes

WAN connection

3G/4G USB modem compatibility
No

DSL WAN
No

Ethernet WAN
Yes

SIM card slot
No

WAN connection type
RJ-45

Weight & dimensions

Depth
147.2 mm

Height
49.2 mm

Width
272.5 mm

Wireless LAN features

Top Wi-Fi standard
Wi-Fi 6E (802.11ax)

Wi-Fi band
Tri-band (2.4 GHz / 5 GHz / 6 GHz)

Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

WLAN data transfer rate (first band)
574 Mbit/s

WLAN data transfer rate (max)
5400 Mbit/s

WLAN data transfer rate (second band)
2402 Mbit/s

WLAN data transfer rate (third band)
2402 Mbit/s
