Description

TP-Link JetStream 16-Port Gigabit Smart Switch with 2 SFP Slots. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 36 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z. Rack mounting, Form factor: 1U

Full Gigabit Ports: 16× gigabit RJ45 ports and 2× gigabit SFP Slots provide high-speed connections
Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring
Centralized Management: Cloud access and Omada app for ultra convenience and easy management
Static Routing: Helps route internal traffic for more efficient use of network resources
Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more
Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping
Standalone Management: Web, CLI (Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities

Product Properties

Manufacturer
TP-LINK

Model
TL-SG2218

EAN
6935364006426

Bullet points

Point
Centralized Management: Cloud access and Omada app for ultra convenience and easy management

Full Gigabit Ports: 16× gigabit RJ45 ports and 2× gigabit SFP Slots provide high-speed connections

Integrated into Omada SDN

Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping

Robust Security Strategies

Standalone Management

Static Routing: Helps route internal traffic for more efficient use of network resources

Certificates

Certification
CE, FCC, RoHS

Data transmission

Forwarding rate
26.8 Mpps

Jumbo frames
9000

Jumbo frames support
Yes

MAC address table
8000 entries

Number of IP interfaces
16

Number of static routes
32

Packet buffer memory
4.1 MB

Static route
Yes

Store-and-forward
Yes

Switching capacity
36 Gbit/s

Design

Form factor
1U

LED indicators
Yes

Product colour
Black

Rack mounting
Yes

Logistics data

Harmonized System (HS) code
85176990

Management features

ARP inspection
Yes

Cloud-managed
Yes

MIB support
Yes

Quality of Service (QoS) support
Yes

Switch layer
L2/L2+

Switch type
Managed

System event log
Yes

Web-based management
Yes

Multicast features

Multicast Listener Discovery (MLD) snooping
Y

Multicast support
Yes

Network

10G support
No

Broadcast storm control
Yes

Ethernet LAN data rates
10,100,1000 Mbit/s

Flow control support
Yes

Link aggregation
Yes

Networking standards
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z

Number of VLANs
4000

Port mirroring
Yes

Rate limiting
Yes

Spanning tree protocol
Yes

Virtual LAN features
Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN

VLAN support
Yes

Operational conditions

Heat dissipation
41.97 BTU/h

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging content

Cables included
AC, LAN (RJ-45)

Quick start guide
Yes

Packaging data

Package depth
528 mm

Package height
80 mm

Package weight
2.45 kg

Package width
250 mm

Performance

Fanless
Yes

Ports & interfaces

Gigabit Ethernet (copper) ports quantity
16

Installed SFP modules quantity
0

Installed SFP+ modules quantity
0

SFP module slots quantity
2

Switch Number of Ports
16

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Power consumption (max)
12.3 W

Power source
AC

Power supply included
Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Protocols

GARP VLAN Registration Protocol (GVRP)
Yes

Management protocols
SNMPv1/v2c/v3, SNTP

Security

Access Control List (ACL)
Yes

BPDU filtering/protection
Yes

DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping

IGMP snooping
Yes

Loop protection
Yes

SSH/SSL support
Yes

Weight & dimensions

Depth
180 mm

Height
44 mm

Width
440 mm
