Description

ATEN 2 Port True 4K HDMI Splitter. Video port type: HDMI, Video out: 2x HDMI. Maximum resolution: 4096 x 2160 pixels, Product colour: Black, Housing material: Aluminium. AC input voltage: 5 V, Power consumption (typical): 1.35 W. Width: 60 mm, Depth: 150 mm, Height: 88 mm. Quantity per pack: 1 pc(s), Package width: 59 mm, Package depth: 119 mm

Distributes one True 4K source to two HDMI displays at the same time
Automatic downscaling function – automatically adjusts the resolution to 1080p for 1080p displays to fit their optimal output
HDMI 2.0 (3D, Deep Color, 4K); HDCP 2.2 compliant
True 4K video resolution (up to 4096 x 2160 @ 60 Hz; 4:4:4); HDR supported
Supports max. data rate up to 18 Gbps (6 Gbps Per Lane)
Supports Dolby TrueHD and DTS-HD Master 7.1 Audio channel
Automatic EDID detection – enjoy high-quality display and use of the best resolution across different screens
Quality and durable aluminum metal enclosure

Product Properties

Manufacturer
Aten

Model
VS82H

EAN
4719264648076

Bullet points

Point
Distributes one True 4K source to two HDMI displays at the same time

HDMI 2.0 (3D, Deep Color, 4K); HDCP 2.2 compliant

Quality and durable aluminum metal enclosure

Supports Dolby TrueHD and DTS-HD Master 7.1 Audio channel

Supports max. data rate up to 18 Gbps (6 Gbps Per Lane)

True 4K video resolution (up to 4096 x 2160 @ 60 Hz; 4:4:4); HDR supported

Features

Bandwidth
600 MHz

Dolby technologies
DTS-HD Master Audio, Dolby TrueHD

HD type
4K Ultra HD

HDCP version
2.2

Housing material
Aluminium

LED indicators
Status

Maximum operating distance
5 m

Maximum refresh rate
60 Hz

Maximum resolution
4096 x 2160 pixels

Product colour
Black

Logistics data

Harmonized System (HS) code
85176990

Master (outer) case gross weight
8.36 kg

Master (outer) case height
338 mm

Master (outer) case length
490 mm

Master (outer) case net weight
4.8 kg

Master (outer) case width
315 mm

Products per master (outer) case
40 pc(s)

Operational conditions

Operating relative humidity (H-H)
0 - 80%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
0 - 80%

Storage temperature (T-T)
-20 - 60 °C

Packaging content

Cables included
Micro-USB

Manual
Yes

Packaging data

Package depth
119 mm

Package height
160 mm

Package weight
196 g

Package width
59 mm

Quantity per pack
1 pc(s)

Ports & interfaces

HDMI version
2.0

Video out
2x HDMI

Video port type
HDMI

Video ports quantity
2

Power

AC input voltage
5 V

Power consumption (typical)
1.35 W

USB powered
Yes

Weight & dimensions

Depth
150 mm

Height
88 mm

Weight
120 g

Width
60 mm
