ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
Roll over image to zoom inClick to Open expanded view
ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
ATEN VE1821-AT-G AV extender AV transmitter & receiver Black
Print
Model: VE1821
EAN: 4710469342790

ATEN VE1821-AT-G AV extender AV transmitter & receiver Black

Manufacturer:
Aten
ATEN VE1821-AT-G, 4096 x 2160 pixels, AV transmitter & receiver, 35 m, Wired, 3D, HDCP
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

ATEN VE1821-AT-G. Type: AV transmitter & receiver, Maximum resolution: 4096 x 2160 pixels, Cable types supported: Cat5e, Cat6. Connectivity technology: Wired. Power source type: DC, Power consumption (receiver) (max): 0.87 W, Power consumption (transmitter) (max): 1.86 mA. Receiver dimensions (WxDxH): 68 x 79.5 x 16.5 mm, Receiver weight: 120 g, Transmitter dimensions (WxDxH): 68 x 79.5 x 16.5 mm. Quantity per pack: 2 pc(s)
  • Crystal clear 4K HDMI transmission with zero latency across up to 40 m via a Cat 6 cable (ATEN 2L-2910 recommended) /30 m via a Cat 5e cable
  • Local HDMI output port on the transmitter unit – enables cascading or users to monitor the UHD signal being extended to the receiver
  • EDID Copying Mode – HDMI source can be displayed at the optimal resolution based on the capabilities of the connected display
  • PoC (Power over Cable) technology – power can be delivered from the transmitter to the receiver via a Cat 5e / 6 cable to eliminate the need for a bulky external power supply

Product Properties

  • Model
  • VE1821
  • EAN
  • 4710469342790
  • Features
  • 3D
  • Yes
  • Bandwidth
  • 10.2 Gbit/s
    340 MHz
  • Cable types supported
  • Cat5e, Cat6
  • HDCP
  • Yes
  • HDCP version
  • 1.4
  • Impedance
  • 100 Ω
  • Material
  • Metal
  • Maximum refresh rate
  • 60 Hz
  • Maximum resolution
  • 4096 x 2160 pixels
  • Maximum transfer distance
  • 35 m
  • Product colour
  • Black
  • Supported graphics resolutions
  • 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160, 4096 x 2160
  • Type
  • AV transmitter & receiver
  • Operational conditions
  • Operating relative humidity (H-H)
  • 20 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage temperature (T-T)
  • -20 - 60 °C
  • Packaging data
  • Quantity per pack
  • 2 pc(s)
  • Ports & interfaces
  • Connectivity technology
  • Wired
  • DC-in jack
  • Yes
  • Ethernet LAN
  • Yes
  • HDMI in
  • 1
  • Number of HDMI outputs
  • 1
  • Remote (IR) input
  • 1
  • Remote (IR) output
  • 1
  • RJ-45 input ports
  • 1
  • RJ-45 output ports
  • 1
  • Power
  • Power consumption (receiver) (max)
  • 0.87 W
  • Power consumption (transmitter) (max)
  • 1.86 mA
  • Power source type
  • DC
  • Weight & dimensions
  • Receiver dimensions (WxDxH)
  • 68 x 79.5 x 16.5 mm
  • Receiver weight
  • 120 g
  • Transmitter dimensions (WxDxH)
  • 68 x 79.5 x 16.5 mm
  • Transmitter weight
  • 120 g
