Description

Epson EB-810E. Projector brightness: 5000 ANSI lumens, Projection technology: 3LCD, Projector native resolution: 1080p (1920x1080). Light source type: Laser, Service life of light source: 20000 h, Service life of light source (economic mode): 30000 h. Focus: Manual, Focal length range: 2.3 mm, Fixed focal length: 2.3 mm. Video processing: 10 bit, Video colour modes: Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation. Serial interface type: RS-232C, Service port type: USB Type-B

Scalable 4KE display for any room: 80-160" UST display for unrestricted viewing (no shadows/reflections)
Bright and energy efficient laser: 5,000 lumens CLO with 3LCD technology for brighter colours
Effortless connectivity options: Auto-on, wired/wireless display with USB 2A output for smart sticks
Simple to use and built to last: Virtually maintenance free with 5-year, 12,000hr warranty
LED/Video wall alternative: Surprisingly affordable with low energy consumption

Legal Statement

Complies with The UK Product Security and Telecommunications Infrastructure (Product Security) requirements. Epson will provide security updates for 7 years from purchase

Product Properties

Manufacturer
Epson

Model
V11HA99080

EAN
8715946718156

Bullet points

Point
Bright and energy efficient laser: 5,000 lumens CLO with 3LCD technology for brighter colours

Effortless connectivity options: Auto-on, wired/wireless display with USB 2A output for smart sticks

LED/Video wall alternative: Surprisingly affordable with low energy consumption

Scalable 4KE display for any room

Simple to use and built to last: Virtually maintenance free with 5-year, 12,000hr warranty

Design

Cable lock slot
Yes

Cable lock slot type
Kensington

Market positioning
Business

Placement
Ceiling, Desktop, Wall

Product colour
White

Product type
Ultra short throw projector

Display

Built-in display
No

Features

High Dynamic Range (HDR) supported
Yes

High Dynamic Range (HDR) technology
High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)

Interactive
No

Noise level
35 dB

Noise level (economic mode)
26 dB

Password protection
Yes

Lens system

F-number (relative aperture)
1.8

Fixed focal length
2.3 mm

Focal length range
2.3 mm

Focus
Manual

Throw ratio
0.16 - 0.22:1

Zoom capability
Yes

Zoom ratio
1.35:1

Light source

Light source type
Laser

Service life of light source
20000 h

Service life of light source (economic mode)
30000 h

Logistics data

Pallet gross height
2.1 m

Pallet gross length
120 cm

Pallet gross width
80 cm

Pallet height (UK)
2.1 m

Pallet length (UK)
120 cm

Products per pallet
12 pc(s)

Products per pallet (UK)
12 pc(s)

Products per pallet layer
2 pc(s)

Products per pallet layer (UK)
2 pc(s)

Quantity per pack
1 pc(s)

Multimedia

Built-in speaker(s)
No

Network

Ethernet LAN
Yes

Ethernet LAN (RJ-45) ports
1

Ethernet LAN data rates
10,100 Mbit/s

Miracast
Yes

Smart TV
No

Wi-Fi
Yes

Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Operational conditions

Operating relative humidity (H-H)
20 - 80%

Operating temperature (T-T)
-10 - 60 °C

Storage relative humidity (H-H)
10 - 90%

Storage temperature (T-T)
-10 - 60 °C

Other features

Box contents
Power cable, Quick Start Guide, Remote control incl. batteries, Warranty Documents

Control panel
0.62 inch with C2 Fine

Interface
USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, HDMI in (2x), HDMI out, HDBaseT, Miracast

Option type
Air filter, Ceiling mount, Connection and control box, MB22 ceiling mount, Safety wire set, Visualiser camera, WP System - ELPWP10, WP System - ELPWP20, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01

Security features
Kensington lock, Control panel lock, Password lock, Padlock, Wireless LAN unit lock, Wireless LAN security, Password protection

Supported network protocols
HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink

Packaging content

Batteries included
Yes

Bundled software
Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management, Epson Setting Assistant

Cables included
AC

Remote control included
Yes

Ports & interfaces

Component video (YPbPr/YCbCr) in
0

Composite video in
0

DVI port
No

HDBaseT port
Yes

HDMI ports
3

Serial interface type
RS-232C

Service port type
USB Type-B

USB 2.0 ports quantity
2

USB 2.0 Type-A ports quantity
2

VGA (D-Sub) ports quantity
0

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Power consumption (economy mode)
286 W

Power consumption (max)
380 W

Power consumption (PowerSave)
0.4 W

Power consumption (typical)
290 W

Power source
AC

Projector

Contrast ratio (dynamic)
5000000:1

Contrast ratio (typical)
2500000:1

Native aspect ratio
16:9

Projection technology
3LCD

Projector brightness
5000 ANSI lumens

Projector brightness (economic mode)
3500 ANSI lumens

Projector native resolution
1080p (1920x1080)

Screen size compatibility
2032 - 4064 mm (80 - 160")

Smart projector
No

Vertical scan range
192 - 240 Hz

Storage

Card reader integrated
No

Technical details

Mobile app support
Yes

Other features
21:9 aspect ratio support, 4K enhancement, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Daisy chain Multi-Projection, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Fit to Screen, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, PC Free, Point correction, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Source function, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App

Video

Analog signal format system
Not supported

Full HD
Yes

Video colour modes
Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation

Video processing
10 bit

Weight & dimensions

Depth
341 mm

Height
156 mm

Package depth
790 mm

Package height
325 mm

Package weight
16.9 kg

Package width
460 mm

Weight
12.5 kg

Width
695 mm
