Description

NETGEAR GSM4328-100AJS. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Installed SFP+ modules quantity: 4. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U

24 Gigabit PoE+ ports with 4 10GBASE-X SFP+ uplinks
880W internal power supply providing 648W of PoE budget
1 slot for modular power supply (1+1 redundancy and/or EPS share)
Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used
The PoE budget can reach 720W, when the redundant PoE budget remains 648W
Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
Layer 3 feature set includes static, policy-based, and dynamic routing
NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations
NETGEAR ProSAFE® Limited Lifetime Hardware Warranty
Lifetime Next Business Day Hardware Replacement

Product Properties

Manufacturer
Netgear

Model
GSM4328-100NES

EAN
606449161922

Bullet points

Point
1 slot for modular power supply (1+1 redundancy and/or EPS share)

24 Gigabit PoE+ ports with 4 10GBASE-X SFP+ uplinks

880W internal power supply providing 648W of PoE budget

Any APS350Wv1, APS600Wv2, APS920Wv1, or APS2000Wv1 can be used

Layer 3 feature set includes static, policy-based, and dynamic routing

Lifetime Next Business Day Hardware Replacement

NETGEAR IGMP Plus™, AV User Interface, and Engage Controller speed up AV installations

NETGEAR ProSAFE® Limited Lifetime Hardware Warranty

The PoE budget can reach 720W, when the redundant PoE budget remains 648W

Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover

Data transmission

MAC address table
16000 entries

Packet buffer memory
16 MB

Switching capacity
128 Gbit/s

Throughput
95.23 Mpps

Design

Form factor
1U

Product colour
Black

Rack mounting
Yes

Stackable
Yes

Management features

Quality of Service (QoS) support
Yes

Switch layer
L3

Switch type
Managed

Traffic shaping
Yes

Web-based management
Yes

Network

10G support
Yes

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x

Number of VLANs
4093

VLAN support
Yes

Operational conditions

Operating temperature (T-T)
0 - 45 °C

Storage temperature (T-T)
-20 - 70 °C

Performance

Noise level
52 dB

Ports & interfaces

Installed SFP modules quantity
0

Installed SFP+ modules quantity
4

Switch Number of Ports
24

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

Power source
AC

Power supply included
Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes

Power over Ethernet (PoE) power per port
30 W

Power over Ethernet plus (PoE+) ports quantity
24

Total Power over Ethernet (PoE) budget
648 W

Security

DHCP features
DHCP server, DHCP snooping, DHCPv6 snooping

Weight & dimensions

Depth
400 mm

Height
43.2 mm

Weight
6.41 kg

Width
440 mm

NETGEAR GSM4328-100AJS Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
