TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+
Roll over image to zoom inClick to Open expanded view
Model: TL-SL1311MP
EAN: 6935364006266

TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+

Manufacturer:
TP-LINK
TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+, Unmanaged, Fast Ethernet (10/100), Power over Ethernet (PoE)
Please log in to see your price
Related products

Description

TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 2000 entries, Switching capacity: 7.6 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 53.5 V. Power connector: DC-in jack. Power over Ethernet (PoE)
  • 8× 10/100 Mbps RJ45 Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
  • 8× PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 124 W for 8 PoE ports*
  • Up to 250 m data and power transmitting range under Extend Mode**
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
  • Fanless Design reduces power consumption and works silently in its location
  • Plug and play with no configuration required

Product Properties

  • Model
  • TL-SL1311MP
  • EAN
  • 6935364006266
  • Bullet points
  • Point
  • 8× 10/100 Mbps RJ45 Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
    8× PoE+ ports transfer data and power on individual cables
    Fanless Design reduces power consumption and works silently in its location
    Isolation Mode allows one-click client traffic separation for higher security and performance
    Plug and play with no configuration required
    Supports PoE Power up to 124 W for 8 PoE ports*
    Supports PoE Power up to 30 W for each PoE port
    Up to 250 m data and power transmitting range under Extend Mode**
    Works with IEEE 802.3af/at compliant PDs
  • Data transmission
  • Forwarding rate
  • 5.6544 Mpps
  • Jumbo frames
  • 16000
  • Jumbo frames support
  • Yes
  • MAC address table
  • 2000 entries
  • Store-and-forward
  • Yes
  • Switching capacity
  • 7.6 Gbit/s
  • Design
  • Number of fans
  • 0 fan(s)
  • Product colour
  • Black
  • Rack mounting
  • No
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • Switch type
  • Unmanaged
  • Network
  • 10G support
  • No
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Cable types supported
  • Cat3, Cat4, Cat5, Cat5e
  • Copper ethernet cabling technology
  • 10BASE-T, 100BASE-TX
  • Networking standards
  • IEEE 802.3af, IEEE 802.3at
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • Manual
  • Yes
  • Packaging data
  • Package type
  • Box
  • Ports & interfaces
  • Installed SFP modules quantity
  • 0
  • Installed SFP+ modules quantity
  • 0
  • Power connector
  • DC-in jack
  • SFP module slots quantity
  • 1
  • Switch Number of Ports
  • 10
  • Switch Port Speed
  • Fast Ethernet (10/100)
  • Power
  • DC input voltage
  • 53.5 V
  • Input current
  • 2.43 A
  • Number of power supply units
  • 1
  • Power supply included
  • Yes
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet plus (PoE+) ports quantity
  • 8
  • Total Power over Ethernet (PoE) budget
  • 124 W
  • Weight & dimensions
  • Depth
  • 126 mm
  • Height
  • 26 mm
  • Width
  • 209 mm
