Description

NETGEAR GS524-300EUS. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

16 or 24 ports deliver up to 2000Mbps of dedicated, non-blocking bandwidth per port
Instant Plug-N-Play connectivity with Auto-negotiation and Auto MDI/MDI-X
Easily combine new or existing 10- 100- and 1000Mbps devices within your network
802.1p QoS support for prioritizing voice and video in the network
Jumbo Frame Support up to 9KB
Fast, auto-switching and auto-sensing 10/100/1000Mbps Ethernet connection
16 or 24 switched ports provide bandwidth for PCs, servers or switches
Auto Uplink™ automatically adjusts for straight-through or crossover cables
Plug and play—begins working as soon as it is powered on
Compact size for desktop, wall mount or rack mount in a standard 19-inch rack
Secure, durable metal housing includes a Kensington locking slot for theft prevention
Backed by a NETGEAR Limited Lifetime Warranty
Honors TOS/802.1p prioritization
Up to 50% lower power consumption
Auto power-down mode saves energy when port is unused
Auto green mode detects cable length and adjusts power usage to save energy
Packaging manufactured with at least 80% recycled materials

Product Properties

Manufacturer
Netgear

Model
GS524-300EUS

EAN
606449164770

Bullet points

Point
16 or 24 ports deliver up to 2000Mbps of dedicated, non-blocking bandwidth per port

16 or 24 switched ports provide bandwidth for PCs, servers or switches

802.1p QoS support for prioritizing voice and video in the network

Auto green mode detects cable length and adjusts power usage to save energy

Auto power-down mode saves energy when port is unused

Auto Uplink™ automatically adjusts for straight-through or crossover cables

Backed by a NETGEAR Limited Lifetime Warranty

Compact size for desktop, wall mount or rack mount in a standard 19-inch rack

Easily combine new or existing 10- 100- and 1000Mbps devices within your network

Fast, auto-switching and auto-sensing 10/100/1000Mbps Ethernet connection

Honors TOS/802.1p prioritization

Instant Plug-N-Play connectivity with Auto-negotiation and Auto MDI/MDI-X

Jumbo Frame Support up to 9KB

Packaging manufactured with at least 80% recycled materials

Plug and play—begins working as soon as it is powered on

Secure, durable metal housing includes a Kensington locking slot for theft prevention

Up to 50% lower power consumption

Certificates

Compliance certificates
CE, Federal Communications Commission (FCC), ISED, UKCA, VCCI

Data transmission

Latency (1 Gbps)
15 µs

Latency (10-100 Mbps)
35 µs

MAC address table
8000 entries

Switching capacity
48 Gbit/s

Design

Product colour
Grey

Management features

Switch type
Unmanaged

Network

Full duplex
Yes

Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Operational conditions

Operating relative humidity (H-H)
0 - 90%

Operating temperature (T-T)
0 - 50 °C

Storage relative humidity (H-H)
0 - 95%

Storage temperature (T-T)
-20 - 70 °C

Performance

Mean time between failures (MTBF)
1016877 h

Ports & interfaces

Switch Number of Ports
24

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Power consumption (max)
12 W

Power source
AC

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Protocols

Switching protocols
Ethernet

Weight & dimensions

Depth
169 mm

Height
43 mm

Weight
1.47 kg

Width
328 mm

NETGEAR GS524-300EUS network switch Unmanaged Gigabit Ethernet (10/100/1000) Grey
