NETGEAR XS508M Unmanaged 10G Ethernet (100/1000/10000) Grey, Silver
Roll over image to zoom inClick to Open expanded view
NETGEAR XS508M Unmanaged 10G Ethernet (100/1000/10000) Grey, Silver
NETGEAR XS508M Unmanaged 10G Ethernet (100/1000/10000) Grey, Silver
Print
Model: XS508M-100EUS
EAN: 606449131116

NETGEAR XS508M Unmanaged 10G Ethernet (100/1000/10000) Grey, Silver

Manufacturer:
Netgear
NETGEAR XS508M, Unmanaged, 10G Ethernet (100/1000/10000), Rack mounting
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

NETGEAR XS508M. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000). MAC address table: 2000 entries, Switching capacity: 160 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3az,.... Power connector: DC-in jack. Rack mounting

Product Properties

  • Model
  • XS508M-100EUS
  • EAN
  • 606449131116
  • Certificates
  • Certification
  • 47 CFR FCC, ICES-003:2016 Issue 6, ANSI C63.4:2014, EN 55032:2012+AC2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2015, VCCI V-3/2015.04, V-4/2012.4, CNS 13438
  • Data transmission
  • Jumbo frames
  • 9000
  • Jumbo frames support
  • Yes
  • MAC address table
  • 2000 entries
  • Switching capacity
  • 160 Gbit/s
  • Design
  • LED indicators
  • Yes
  • Product colour
  • Grey, Silver
  • Rack mounting
  • Yes
  • Safety
  • CE: CB 60950-1, LVD 60950-1, AUS/NZ: AS/NZS 60950-1, USA: UL 60950-1, SNE VA, BSMI
  • Logistics data
  • Harmonized System (HS) code
  • 85176990
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Switch type
  • Unmanaged
  • Network
  • 10G support
  • Yes
  • Networking standards
  • IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • Operational conditions
  • Heat dissipation
  • 147.86 BTU/h
  • Operating altitude
  • 0 - 3000 m
  • Operating relative humidity (H-H)
  • 0 - 95%
  • Operating temperature (T-T)
  • 0 - 50 °C
  • Storage relative humidity (H-H)
  • 0 - 95%
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Performance
  • Mean time between failures (MTBF)
  • 1145157 h
  • Ports & interfaces
  • Gigabit Ethernet (copper) ports quantity
  • 7
  • Power connector
  • DC-in jack
  • SFP+ module slots quantity
  • 1
  • Switch Port Speed
  • 10G Ethernet (100/1000/10000)
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 240 V
  • Input current
  • 1.5 A
  • Power consumption (max)
  • 39 W
  • Power consumption (typical)
  • 21.31 W
  • Power source
  • AC
  • Weight & dimensions
  • Depth
  • 169 mm
  • Height
  • 43.2 mm
  • Weight
  • 1.49 kg
  • Width
  • 328 mm
