Intel Core i3-10105 processor 3.7 GHz 6 MB Smart Cache Box
Roll over image to zoom inClick to Open expanded view
Model: BX8070110105
EAN: 5032037214841

Intel Core i3-10105 processor 3.7 GHz 6 MB Smart Cache Box

Manufacturer:
Intel
Intel Core i3-10105, Intel® Core™ i3, LGA 1200 (Socket H5), 14 nm, Box, Intel, i3-10105
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

Intel Core i3-10105. Processor family: Intel® Core™ i3, Processor socket: LGA 1200 (Socket H5), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel® UHD Graphics 630, Maximum on-board graphics card memory: 64 GB, On-board graphics card base frequency: 350 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express configurations: 1x16, 2x8, 1x8+2x4. Intel® Turbo Boost Technology 2.0 frequency: 4.4 GHz

Product Properties

  • Model
  • BX8070110105
  • EAN
  • 5032037214841
  • Features
  • Commodity Classification Automated Tracking System (CCATS)
  • G077159
  • CPU configuration (max)
  • 1
  • Embedded options available
  • No
  • Execute Disable Bit
  • Yes
  • Export Control Classification Number (ECCN)
  • 5A992.C
  • Idle States
  • Yes
  • Market segment
  • Desktop
  • Maximum number of PCI Express lanes
  • 16
  • PCI Express configurations
  • 1x16, 2x8, 1x8+2x4
  • PCI Express slots version
  • 3.0
  • Scalability
  • 1S
  • Supported instruction sets
  • SSE4.1, SSE4.2, AVX 2.0
  • Thermal Monitoring Technologies
  • Yes
  • Thermal solution specification
  • PCG 2015C
  • Use conditions
  • PC/Client/Tablet
  • Graphics
  • Discrete graphics card
  • No
  • Discrete graphics card model
  • Not available
  • Maximum on-board graphics card memory
  • 64 GB
  • Number of displays supported (on-board graphics)
  • 3
  • On-board graphics card
  • Yes
  • On-board graphics card 4K support
  • Yes
  • On-board graphics card base frequency
  • 350 MHz
  • On-board graphics card DirectX version
  • 12.0
  • On-board graphics card dynamic frequency (max)
  • 1.1 MHz
  • On-board graphics card ID
  • 0x9BC8
  • On-board graphics card maximum resolution (DisplayPort)
  • 4096 x 2304 pixels
  • On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
  • 4096 x 2304 pixels
  • On-board graphics card maximum resolution (HDMI)
  • 4096 x 2160 pixels
  • On-board graphics card model
  • Intel® UHD Graphics 630
  • On-board graphics card OpenGL version
  • 4.5
  • On-board graphics card refresh rate at maximum resolution (DisplayPort)
  • 60 Hz
  • On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
  • 60 Hz
  • On-board graphics card refresh rate at maximum resolution (HDMI)
  • 30 Hz
  • Logistics data
  • Harmonized System (HS) code
  • 85423119
  • Memory
  • ECC
  • No
  • Maximum internal memory supported by processor
  • 128 GB
  • Memory bandwidth (max)
  • 41.6 GB/s
  • Memory channels
  • Dual-channel
  • Memory clock speeds supported by processor
  • 2666 MHz
  • Memory types supported by processor
  • DDR4-SDRAM
  • Operational conditions
  • Tjunction
  • 100 °C
  • Other features
  • Maximum internal memory
  • 128 GB
  • Processor
  • Component for
  • PC
  • Cooler included
  • Yes
  • Memory bandwidth supported by processor (max)
  • 41.6 GB/s
  • Number of Cores
  • 4
  • Package type
  • Box
  • Processor
  • i3-10105
  • Processor ARK ID
  • 201894
  • Processor base frequency
  • 3.7 GHz
  • Processor boost frequency
  • 4.4 GHz
  • Processor cache
  • 6 MB
  • Processor cache type
  • Smart Cache
  • Processor codename
  • Comet Lake
  • Processor family
  • Intel® Core™ i3
  • Processor generation
  • 10th gen Intel® Core™ i3
  • Processor lithography
  • 14 nm
  • Processor manufacturer
  • Intel
  • Processor operating modes
  • 64-bit
  • Processor socket
  • LGA 1200 (Socket H5)
  • Processor threads
  • 8
  • System bus rate
  • 8 GT/s
  • Thermal Design Power (TDP)
  • 65 W
  • Processor special features
  • Enhanced Intel SpeedStep Technology
  • Yes
  • Intel 64
  • Yes
  • Intel Clear Video Technology
  • Yes
  • Intel Enhanced Halt State
  • Yes
  • Intel Software Guard Extensions (Intel SGX)
  • Yes
  • Intel Stable Image Platform Program (SIPP)
  • No
  • Intel Trusted Execution Technology
  • No
  • Intel Turbo Boost Max Technology 3.0
  • No
  • Intel Virtualization Technology (VT-x)
  • Yes
  • Intel Virtualization Technology for Directed I/O (VT-d)
  • Yes
  • Intel VT-x with Extended Page Tables (EPT)
  • Yes
  • Intel® AES New Instructions (Intel® AES-NI)
  • Yes
  • Intel® Boot Guard
  • Yes
  • Intel® Clear Video HD Technology (Intel® CVT HD)
  • Yes
  • Intel® Hyper Threading Technology (Intel® HT Technology)
  • Yes
  • Intel® Identity Protection Technology (Intel® IPT)
  • Yes
  • Intel® InTru™ 3D Technology
  • Yes
  • Intel® Optane™ Memory Ready
  • Yes
  • Intel® OS Guard
  • Yes
  • Intel® Quick Sync Video Technology
  • Yes
  • Intel® Secure Key
  • Yes
  • Intel® Stable IT Platform Program (SIPP)
  • No
  • Intel® Thermal Velocity Boost
  • No
  • Intel® Transactional Synchronization Extensions
  • No
  • Intel® Turbo Boost Technology
  • 2.0
  • Intel® Turbo Boost Technology 2.0 frequency
  • 4.4 GHz
  • Intel® vPro™ Platform Eligibility
  • No
  • Technical details
  • Bus speed
  • 8 GT/s
  • Launch date
  • Q1'21
  • OpenGL support
  • Yes
  • Status
  • Launched
  • Supported memory types
  • DDR4-SDRAM
  • Weight & dimensions
  • Processor package size
  • 37.5 x 37.5 mm
